AMD Ryzen 7 5800X3D processor

AMD Ryzen 7 5800X3D. Processor family: AMD Ryzen™ 7, Processor socket: Socket AM4, Processor lithography: 7 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM. Processing Die size: 74 mm², Compatible operating systems: Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit

The AMD Ryzen™ 7 5800X3D is the ultimate gaming processor on any DDR4 platform. Every 10th Anniversary Edition AMD Ryzen™ 7 5800X3D Processor includes a Carbice® Ice Pad™.

Processor

Processor manufacturer: AMD
Processor generation: AMD Ryzen 5000 Series
Processor model: 5800X3D
Processor base frequency: 3.4 GHz
Processor family: AMD Ryzen™ 7
Processor cores: 8
Processor socket: Socket AM4
Processor lithography: 7 nm
Processor threads: 16
Processor operating modes: 64-bit
Processor boost frequency: 4.5 GHz
Processor cache: 96 MB
Processor cache type: L3
Thermal Design Power (TDP): 105 W
Package type: Box
Compatible chipsets: AMD X470, AMD A520, AMD B450, AMD B550, AMD X570

Memory

Maximum internal memory supported by processor: 128 GB
Memory types supported by processor: DDR4-SDRAM
Memory clock speeds supported by processor: 2667,2933,3200 MHz
Memory channels: Dual-channel
Feature: ECC

Graphics

On-board graphics card model: Not available
Discrete graphics card model: Not available

Features

PCI Express slots version: 4.0
Processing Die size: 74 mm²
Compatible operating systems: Windows 11 - 64-Bit EditionWindows 10 - 64-Bit EditionRHEL x86 64-BitUbuntu x86 64-Bit

Operational conditions

Minimum operating temperature: 90 °C
