CASE FAN 140MM PURE WINGS 3 / PWM HIGH-SPEED BL109 BE QUIET
Product reference:
2-4260052190814
CASE FAN 140MM PURE WINGS 3 / PWM HIGH-SPEED BL109 BE QUIET
Product reference:
2-4260052190814
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Lithuania in
3 - 5
business days
Not available
Performant, Progressive, Quiet
Pure Wings 3 140mm PWM high-speed are the perfect addition to demanding PCs with extraordinarily high performance and progressive features such as a speed-regulating closed loop motor. This makes the fan a versatile companion for your gaming system. Its iconic design lets anyone immediately recognize it as be quiet! fan and adds a touch of elegance to any configuration.
- Innovative closed loop motor keeps the rpm no matter the resistance
- Optimized fan frame for outstanding performance on radiators
- Newly designed fan blades and re-arranged angle for extraordinary air pressure
- Pure Wings 3 140mm PWM high-speed can be operated with very low minimum rpm for very quiet operation
- Long life rifle bearing gives an operating lifetime of 80,000 hours
- Iconic, unmistakable and streamlined design that avoids anything unnecessary
- Product conception, design and quality control in Germany
| Airflow | 122.6 m³/h |
| Cable length | 0.46 m |
| Compliance certificates | CE/RoHS/UKCA/WEEE |
| Depth | 140 mm |
| Fan bearing technology | Rifle bearing |
| Fan connector | 4-pin |
| Fan current | 0.12 A |
| Fan diameter | 140 mm |
| Fan power consumption | 6 W |
| Fan's mean time to failure (MTTF) | 80000 h |
| Height | 25 mm |
| Maximum air pressure | 2.44 mmH2O |
| Maximum airflow | 72.2 cfm |
| Model | BL109 |
| Model name | Pure Wings 3 140mm PWM high-speed |
| Noise level (high speed) | 30.5 dB |
| Number of fans | 1 fan(s) |
| Number of screws | 4 |
| Package depth | 174 mm |
| Package height | 27 mm |
| Package weight | 221 g |
| Package width | 142 mm |
| Product colour | Black |
| Products per shipping (inner) case | 72 pc(s) |
| Pulse-width modulation (PWM) support | Yes |
| Quantity per pack | 1 pc(s) |
| Rated voltage | 12 V |
| Rotational speed (max) | 1800 RPM |
| Screws included | Yes |
| Shipping (inner) case gross weight | 17460 g |
| Shipping (inner) case height | 370 mm |
| Shipping (inner) case length | 482 mm |
| Shipping (inner) case width | 395 mm |
| Suitable location | Computer case |
| Summary | be quiet! Pure Wings 3 140mm PWM high-speed. Type: Fan, Fan diameter: 14 cm, Rotational speed (max): 1800 RPM, Airflow: 122.6 m³/h, Maximum air pressure: 2.44 mmH2O. Voltage: 5 - 13.2 V. Width: 140 mm, Depth: 140 mm, Height: 25 mm. Product colour: Black |
| Sustainability certificates | Triman |
| Sustainability compliance | Yes |
| Type | Fan |
| Unit Box Height | 0.145 |
| Unit Box Length | 0.15 |
| Unit Box Width | 0.03 |
| Unit Calculated Volume | 0.0009134 cubm |
| Unit Calculated Weight | 0.248 kg |
| Units per Shipping Box | 72 |
| Vendor Homepage | https://www.bequiet.com/en/download/casefans/4603?utm_source=newsletter |
| Voltage | 5 - 13.2 V |
| Weight | 188 g |
| Width | 140 mm |
