Zyxel XMG2230-28HP Managed L2 / L3 2.5G Ethernet (100 / 1000 / 2500) Power over Ethernet (PoE) 1U Black
Product reference:
6-XMG2230-28HP-ZZ0101F
Zyxel XMG2230-28HP Managed L2/L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Black
Zyxel XMG2230-28HP Managed L2 / L3 2.5G Ethernet (100 / 1000 / 2500) Power over Ethernet (PoE) 1U Black
Product reference:
6-XMG2230-28HP-ZZ0101F
Zyxel XMG2230-28HP Managed L2/L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Black
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
120 month
Delivery from Europe in
5 - 9
business days
| 10G support | Yes |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| ARP inspection | Yes |
| Authentication | Guest VLAN, MAC-based authentication |
| Authentication type | IEEE 802.1x, NAC SSH V2.0, RADIUS, TACACS+ |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| BPDU filtering/protection | Yes |
| Broadcast storm control | Yes |
| Certification | FCC Part 15 (Class A) CE EMC (Class A) BSMI EMC |
| Cloud-managed | Yes |
| Compliance certificates | BSMI, Low Voltage Directive (LVD), RoHS |
| Configuring Location Settings (CLI) | Yes |
| Console port | RJ-45/USB Type-C |
| Copper ethernet cabling technology | 2.5GBASE-T, 100BASE-T, 1000BASE-T |
| DC input voltage | 50 - 57 V |
| Depth | 330 mm |
| DHCP features | DHCP client, DHCP Option 60, DHCP Option 82, DHCP relay, DHCP server, DHCP snooping, DHCPv6 relay, DHCPv6 snooping |
| Flash memory | 64 MB |
| Form factor | 1U |
| Forwarding rate | 148.8 Mpps |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Heat dissipation | 2856 BTU/h |
| Height | 44 mm |
| IGMP proxy | Yes |
| IGMP snooping | Yes |
| Internal memory | 1000 MB |
| IP-MAC-Port binding | Yes |
| IPv4 & IPv6 features | Dual stack IPv4/IPv6, ICMPv6, IPv6 Path MTU Discovery, IPv6 Telnet |
| Jumbo frames | 12 |
| Jumbo frames support | Yes |
| LED indicators | Yes |
| MAC address table | 32000 entries |
| Mean time between failures (MTBF) | 554612.62 h |
| Multicast support | Yes |
| Networking standards | IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3x, IEEE 802.3z |
| Noise level | 48.85 dB |
| Number of IP interfaces | 32 |
| Number of static routes | 4000 |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -20 - 50 °C |
| Packet buffer memory | 2 MB |
| Policy-based routing | Yes |
| Port mirroring | Yes |
| Power consumption (max) | 1519.1 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | PoE++ (4PPoE) |
| Power source | AC/PoE |
| Power supply included | Yes |
| Product colour | Black |
| Quality of Service (QoS) support | Yes |
| Rack mounting | Yes |
| Rate limiting | Yes |
| Routing entries | 64 |
| Security algorithms | SNMP, SNMPv2, SNMPv3 |
| SFP+ module slots quantity | 4 |
| SSH/SSL support | Yes |
| Stackable | Yes |
| Static port security | Yes |
| Static route | Yes |
| Storage relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -40 - 70 °C |
| Switch layer | L2/L3 |
| Switch type | Managed |
| Switching capacity | 200 Gbit/s |
| Total Power over Ethernet (PoE) budget | 1440 W |
| Virtual LAN features | IP subnet-based VLAN, Policy-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN |
| Weight | 4.53 kg |
| Width | 441 mm |
