UPS power supply Ubiquiti UPS-2U-EU 1500VA / 1000W (230V, 2xGbE, 2x12V 9Ah, 4xC13, IP20)
Product reference:
26-UBIQUITIUPS2UEU
- Type: Backup power supply (UPS)
- Brand: Ubiquiti
- Model: UPS-TOWER 1000VA/600W
- Voltage: 230 V (input 170-280 V AC)
- Power: 1000 VA / 600 W
- Battery: 12V, 9Ah
- Wave: Simulated sine wave
- Connectors: 5 × IEC C13 with overcurrent protection up to 250 V AC / 10 A, LAN 10/100
- Protection class: IP20
- Operating temperature: 0 40 °C
- Dimensions (W×H×D): 288 × 99 × 280.5 mm
UPS power supply Ubiquiti UPS-2U-EU 1500VA / 1000W (230V, 2xGbE, 2x12V 9Ah, 4xC13, IP20)
Product reference:
26-UBIQUITIUPS2UEU
- Type: Backup power supply (UPS)
- Brand: Ubiquiti
- Model: UPS-TOWER 1000VA/600W
- Voltage: 230 V (input 170-280 V AC)
- Power: 1000 VA / 600 W
- Battery: 12V, 9Ah
- Wave: Simulated sine wave
- Connectors: 5 × IEC C13 with overcurrent protection up to 250 V AC / 10 A, LAN 10/100
- Protection class: IP20
- Operating temperature: 0 40 °C
- Dimensions (W×H×D): 288 × 99 × 280.5 mm
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
2 - 4
business days
- General information
- Dimensions 442.4 x 300 x 87.4 mm (17.4 x 11.8 x 3.4")
- Weight 13.7 kg (30.2 lb)
- Housing material Galvanized steel
- Form factor Rack mount (2U)
- Weather resistance/outdoor conditions IP20
- Management Ethernet
- Network interface (1) 100/10 MbE port for network connection, (2) GbE ports for surge in/out
- Power Inputs (1) OVC II AC in: C14 socket, 1.8 m (5.9 ft) removable power cord
- Power Outputs (4) Battery backup/surge protection: C13, (4) Surge protection: C13
- Capacity 1,500VA / 1,000W
- UPS type Line interactive
- Input voltage range 170—280V AC
- Power supply method (1) TN system, 220—240V AC, 10A Max., 50/60 Hz
- Rated input voltage 230V AC
- Output voltage 220—240V AC
- Nominal Output Voltage 230V AC
- Frequency range AC mode: 50/60 Hz ±5 Hz (Auto sensing), Battery mode: 50 Hz ±1 Hz
- AC Voltage Regulation ±10% (Battery mode)
- Switching time 6 ms typical; 10 ms max. (Battery mode)
- Waveform (battery mode) Simulated sine wave
- Battery type (2) Lead Acid 12V, 9Ah
- Runtime at Full Load 2.3 minutes
- Runtime at Half Load 8 minutes
- Battery charging time 6-8 hours to 90% capacity
- Overload Protection (Online Mode) 110% for 5 min then fault, 120% immediate fault
- Overload Protection (Battery Mode) 110% shutdown in 5 seconds, 120% shutdown immediately
- Short Circuit Protection (Online Mode) Breaker, 250V AC, 10A
- Output Short-Circuit Current Ipeak: 444.0A, Irms: 223.1A
- Buttons (1) Power, (1) Factory reset
- LED indicators Status indicators: Off, Flashing white, Steady white, Steady blue, Flashing blue, Alternating white/blue, Rapid flashing blue, Steady red, Flashing red
- Working height 3,000 m (1.9 mi)
- Work environment Pollution Degree 2
- Ambient Storage Temperature -20 to 50°C (-4 to 122°F)
- Ambient operating temperature 0 to 40°C (32 to 104°F)
- Ambient operating humidity 0 to 95% non-condensing
- Certificates CE, IEC 62040-1
| Manufacturer | Ubiquiti |
| Manufacturer code | UBIQUITIUPS2UEU |
| Weight | 14.6 kg |
