Hikvision multi-input transmitter DS-PM1-I16O2-WE AX PRO
Product reference: 26-6931847131166
  • Frequency: 868Mhz
  • AES-128 encryption
  • 16 input ports
  • 2 output ports
  • Enough space for a 12v 7AH battery (151x65x94mm)
Hikvision multi-input transmitter DS-PM1-I16O2-WE AX PRO

Hikvision multi-input transmitter DS-PM1-I16O2-WE AX PRO

Product reference: 26-6931847131166
  • Frequency: 868Mhz
  • AES-128 encryption
  • 16 input ports
  • 2 output ports
  • Enough space for a 12v 7AH battery (151x65x94mm)
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
13241 €
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
2 - 6
business days

Your message has been successfully sent!
Fill in the required fields*
Software features
Resistance1k 2.2k 4.7k 8.2k NO/NC
Serial port1
Battery port1, 12 VDC input
Anti-counterfeiting protectionFront and rear
Energy exchange1
Warning signal input16
Warning signal output2
Power output2 (12V, total 1A)
Electrical functions
Battery typeCompatible with 12V 7 Ah 150 × 64 × 94 mm
Energy source100-240VAC, 30W
Moisture resistance10% to 90%
Temperature resistance-10°C to 55°C
Energy consumptionBattery Supply: Quiescent current (50 mA), Max current (1500 mA), Voltage (13.8 V) 220 V Supply: Quiescent current (45 mA), Max current (300 mA), Voltage (220 V)
Battery lifeUp to 36 hours
Wireless transmission
RF frequency868MHz
RF methodTwo-way communication
RF modulation2GFSK
RF distance1100 m
Image settings
Indicators3: Power(Green), Fault(Amber), Signal Strength(Green/Red)
Home
Installation methodWall Mounting
Dimensions (W x H x D)261 x 199 x 86.4 mm
MaterialPlastic
ColorWhite

Weight1.14 kg
