Hikvision dome DS-2CD2E43G2-U F2.8 (white, 4 MP, AcuSense)
Product reference:
26-6931847135119
- MP (MegaPixel): 4 MP
- Lens: 2.8 mm, horizontal FOV: 103°
- Technology: AcuSense
- Built-in microphone: Yes
- microSD slot: Yes, 256GB
- Operating conditions: -10 °C to 50 °C
- Video compression: H.264
- WiFi: No
- The set includes white and black covers.
Hikvision dome DS-2CD2E43G2-U F2.8 (white, 4 MP, AcuSense)
Product reference:
26-6931847135119
- MP (MegaPixel): 4 MP
- Lens: 2.8 mm, horizontal FOV: 103°
- Technology: AcuSense
- Built-in microphone: Yes
- microSD slot: Yes, 256GB
- Operating conditions: -10 °C to 50 °C
- Video compression: H.264
- WiFi: No
- The set includes white and black covers.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
2 - 6
business days
- Camera
- Sensor 1/3" Progressive Scan CMOS
- Max resolution 2688 × 1520
- Min. lighting Color: 0.005 Lux @ (F1.6, AGC ON)
- Shutter speed 1/3 s to 1/100,000 s
- Changing the angle Tilt: 0° to 75°
- Lens
- Lens Type FOV
2.8 mm, horizontal FOV 103°, vertical FOV 55°, diagonal FOV 122°
4 mm, horizontal FOV 84°, vertical FOV 43°, diagonal FOV 100°
- Aperture F1.6
- Lens installation M12
- DOROUS
- DOROUS
2.8mm: D: 56m, O: 22m, R: 11m, I: 6m
4mm: D: 85m, O: 34m, R: 17m, I: 9m
- Image
- Main stream
50Hz: 25fps (2688×1520, 1920×1080, 1280×720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub Stream
50Hz: 25fps (640×480, 640×360)
60Hz: 30fps (640×480, 640×360)
- Third stream
50Hz: 10fps (1920×1080, 1280×720, 640×480, 640×360)
60Hz: 10fps (1920×1080, 1280×720, 640×480, 640×360)
- Image compression
Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
- Video bit rate 32 Kbps to 8 Mbps
- H.264 type Baseline Profile/Main Profile/High Profile
- H.265 type Main Profile
- Bit rate control CBR/VBR
- SVC
Yes
- ROI 1 fixed region for main stream and sub-stream
- Sound
- Removing extraneous sounds Yes
- Audio sampling frequency 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
- Audio compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
- Audio bit rate 64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/16Kbps-64Kbps(AAC)/32-192Kbps(MP2L2)/8-320Kbps(MP3)
- Internet
- Live video viewing Up to 6 channels
- API Open Network Video Interface (Profile S, Profile G), ISAPI, SDK, ISUP
- Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
- User/Host Up to 32 users. 3 user levels: administrator, operator and user
- Security Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
- Internal memory NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
- Customer iVMS-4200, Hik-Connect, Hik-Central
- Browser
Plug-in required live view: IE 10, IE 11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
- Photo
- WDR 120 dB
- Day/Night mode Day, Night, Auto, Schedule
- Photo beautification BLC, HLC, 3D DNA
- Photo parameters converter Yes
- Photo settings Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
- Interface
- Built-in microphone Yes
- Storage location Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
- Resetting the device Yes
- Communication interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
- Features
- Main functions Motion detection (human and vehicle targets classification), video tampering alarm, exception
- Facial recognition Yes
- Smart features
- Perimeter security
Line crossing, intrusion
Support alarm triggering by specified target types (human and vehicle)
- Home
- System parameters
12 VDC ± 25%, 0.27 A, max. 3.2 W, two-core terminal block
PoE: (802.3af, 36 V to 57 V), Class 3, 0.12 A to 0.07 A, max. 4.2 W
- Linking method Upload to FTP/memory card/NAS, notify surveillance center, trigger recording, trigger capture, send email
- Web browser language
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Main functions Anti-flicker, heartbeat, password reset via email, pixel counter
- Storage conditions -10 °C to 50 °C (14 °F to 122 °F). Humidity 95% or less (non-condensing)
- Working conditions -10 °C to 50 °C (14 °F to 122 °F). Humidity 95% or less (non-condensing)
- Material Plastic body
- Camera size Ø93.9 × 117.5 mm (Ø3.7" × 4.6")
- Package size 135 × 135 × 183 mm (5.3" × 5.3" × 7.2")
- Camera weight Approx. 155 g (0.3 lb.)
- Weight with packaging Approx. 325 g (0.7 lb.)
- Approvals
- EMC
FCC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015)
- Security
UL (UL 62368-1);
CB (IEC 62368-1:2014+A11);
CE-LVD (EN 62368-1:2014/A11:2017)
- Environmental protection
CE-RoHS (2011/65/EU);
WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
| Weight | 0.182 kg |
