Hikvision card reader DS-K1101M
Product reference: 26-6954273635671
  • Supports Mifare 1 card (Reading frequency 13.56 MHz)
  • Without keyboard
  • Communication interface: RS485 and Wiegand output,
  • Protection against disassembly
  • Integrated buzzer
  • IP64
Hikvision card reader DS-K1101M

Hikvision card reader DS-K1101M

Product reference: 26-6954273635671
  • Supports Mifare 1 card (Reading frequency 13.56 MHz)
  • Without keyboard
  • Communication interface: RS485 and Wiegand output,
  • Protection against disassembly
  • Integrated buzzer
  • IP64
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
29,03 €
Last product in warehouse

Guarantee
24 month

Delivery from Lithuania in
2 - 4
business days

Your message has been successfully sent!
Fill in the required fields*
Not available

Power supply

12V DC

Current consumption

≤500mA

Processor

32-bit

Reading frequency

13.56MHz

Scanning distance

30 to 50mm (1.18 to 1.96")

ID settings

Setting by the DIP Switch on the Main Board

Audible warning

Beeper

Energy consumption

≤6W

Certificates

FCC, CE

LED Indication

Power Indicator; Status LED Indicator

Working temperature

-40°C to +70°C (-40°F to +158°F)

Relative humidity

10% to 90% (Non-Condensing)

IP protection class

IP64

Measurements

132.0×92.3×20.5mm (5.20×3.63×0.81")

Weight

≤ 0.14Kg

Installation method

Applied for 120 Gang Box Only


ManufacturerHikvision
Manufacturer codePSSDSK1101M
Weight0.11 kg
