- In stock.
Detector Hik-vision DS-PRI120
Product reference:
26-6941264024965
- Detection angle: 120°
- Detection range: 120 m
- Line crossing (up to 4 trigger lines) and zone alarm (up to 16 zones)
- Selectable frequency band
- Connection of up to 4 high-speed PTZ cameras for automatic target tracking (cameras can be mounted separately)
- Connecting to multiple network cameras for alarm recording via iVMS-4200
- Radar and PTZ camera interface: smooth video stream, forced tracking target switching, parking action and field of view display
- Multiple radars can be linked to one PTZ camera
- Up to 4 targets can be tracked by 4 PTZ cameras separately
- Optimized user interface: visible zone drawing path, movable zones, editable zone shapes
- Movable trigger lines, changing line length and direction
- Detection of extremely slow movements, squatting or crawling
- The client application displays the distance, direction and position of the detected object
- Selectable operating modes: open space, scrub and individual mode (adjustable sensitivity)
- Reliable operation 24/7 in all weather conditions
- Event alarm: communication failure, movement, tampering, occlusion detection
- Two-color indicator shows radar status
- Power supply: standard PoE and 12 V DC
Detector Hik-vision DS-PRI120
Product reference:
26-6941264024965
- Detection angle: 120°
- Detection range: 120 m
- Line crossing (up to 4 trigger lines) and zone alarm (up to 16 zones)
- Selectable frequency band
- Connection of up to 4 high-speed PTZ cameras for automatic target tracking (cameras can be mounted separately)
- Connecting to multiple network cameras for alarm recording via iVMS-4200
- Radar and PTZ camera interface: smooth video stream, forced tracking target switching, parking action and field of view display
- Multiple radars can be linked to one PTZ camera
- Up to 4 targets can be tracked by 4 PTZ cameras separately
- Optimized user interface: visible zone drawing path, movable zones, editable zone shapes
- Movable trigger lines, changing line length and direction
- Detection of extremely slow movements, squatting or crawling
- The client application displays the distance, direction and position of the detected object
- Selectable operating modes: open space, scrub and individual mode (adjustable sensitivity)
- Reliable operation 24/7 in all weather conditions
- Event alarm: communication failure, movement, tampering, occlusion detection
- Two-color indicator shows radar status
- Power supply: standard PoE and 12 V DC
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
2 - 6
business days
- Detection performance
- Date Fresh rate 10 frames/s
- Locking angle 120°
- Capture range 120m
- Max. Target number 64
- Microwave frequency 24.05~24.25GHz
- Protection against animal capture 20kg
- Radar transmit power ＜20dBm
- Range measurement accuracy ± 1.5m
- Velocity measurement accuracy ± 0.152m/s
- Velocity range -9.8 to 9.8 m/s
- Electrical characteristics
- Energy consumption <8W
- Power source Standard PoE / 12VDC
- General
- Anti-corrosion NEMA 4X
- Application scenario Outdoor
- Holder Multiple brackets
- Color White
- Dimensions (W x H x D) 206 mm × 228 mm × 61 mm (8.11" × 8.98" × 2.40")
- IK Wheel IK09
- IP Rate IP67
- Mounting height 2 - 3m (Recommend Height: 2.5m)
- Installation method Multiple installations with different brackets
- Working conditions humidity 10% to 90%
- Working condition temperature -40 to 65
- Housing material PC+ABS
- Weight 1.9 kg
- Hardware features
- Alarm output 4 Relay Outputs(NO/NC)
- Indicator Dual-color LED
- Network interface 1 RJ45 10M/100M self-adaptive, PoE
- Power interface 802.3at standard PoE or 12VDC
- Relay output 3-ch: 0.5A/125VAC, breakdown voltage: 1kV1-ch: 10A/240VAC. Breakdown voltage: 2.5kV
- Serial port RS485
- RF transmission
- RF Modulation FMCW
- Software features
- Configuration tools Web / iVMS-4200
- Exception detection Communication failure alarm, Movement alarm
- Firmware update tools Web / iVMS-4200
- Protocol HTTP, DNS, NTP, TCP, UDP, DHCP, ARP, SSH
- Schedule Auto Arm/Disarm Schedule
- Signal strength indication ；Signal Strength Indicators (SSI)；
- Protection against counterfeiting Tamper alarm
- Trigger line Up to 4 Trigger Lines
- Zones 16
| Weight | 2.426 kg |
