6-port, 4 PoE switch UTP6306S-PSB
Product reference: 26-SWITCHUTP6306S-PSB
  • 4*10/100/1000 Base-T PoE RJ-45 ports
  • 2*1000 Base-X SFP ports
  • 1*RJ-45 console port
  • Operating temperature: -40~75
  • Redundant power supply
  • 8kV contact discharge, 12kV air discharge ESD protection
  • Fanless metal case design
  • DIN rail mounting
6-port, 4 PoE switch UTP6306S-PSB

6-port, 4 PoE switch UTP6306S-PSB

Product reference: 26-SWITCHUTP6306S-PSB
  • 4*10/100/1000 Base-T PoE RJ-45 ports
  • 2*1000 Base-X SFP ports
  • 1*RJ-45 console port
  • Operating temperature: -40~75
  • Redundant power supply
  • 8kV contact discharge, 12kV air discharge ESD protection
  • Fanless metal case design
  • DIN rail mounting
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
172,80 €
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
2 - 4
business days

Your message has been successfully sent!
Fill in the required fields*
  • Home
  • Device UTP3306TS-PSD
  • Downlink ports 4*10/100/1000 Base-T PoE++ RJ-45(Auto-MDI/MDI-X)
  • Uplink ports 1*10/100/1000 Base-T RJ-451*1000 Base-X SFP
  • LED indicators 1*PWR, power supply indicators1*Link/Act, SFP port state indicators
  • Size 294mm*180mm*44mm
  • Input voltage 100~240V AC, 50~60Hz
  • Energy consumption ≤370W (Full load including PoE)
  • Material Metal shell
  • Installation Rack/Desktop/Wall mounted
  • Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
  • Forwarding modes Store and Forward
  • MAC address table 2k, support auto learning
  • Switching capacity 12Gbps/non-blocking
  • Packet forwarding speed 8.928Mpps
  • Port Buffer 1MB
  • Jumbo Frame 9716 Bytes
  • PoE standard IEEE 802.3af/at/bt
  • PoE power type End span
  • PoE layout 3/6/4/5(+), 1/2/7/8(-)
  • PoE budget 90W max for each port, 360W max for whole switch
  • Working conditions temperature -10 ~50, 5%~95% (Non-condensation)
  • Storage -40 ~70, 5%~95% (Non-condensation)
  • Certificates CE, FCC
  • System information System, Hardware, Time and Firmware
  • IP status IP Interfaces, IP Routes and ARP Table
  • System messages System Log Information
  • Detailed system messages ID and Message
  • MAC address table MAC Address Table: Type, VLAN, MAC Address, CPU and Port Number
  • VLANs Membership and Ports
  • Ports Traffic Overview and Detailed Statistics
  • LACP System Status, Port Status and Port Statistics
  • Overheating protection Thermal Protection Port Status
  • Green Ethernet Port Power Savings Status
  • PoE status Power Over Ethernet Status
  • LLDP Thermal Protection Port Status
  • Loop Protection Loop Protection Status
  • Comprehensive protocols Bridge Status, Port Status and Port Statistics
  • IGMP Snooping IGMP Snooping Status, Groups Information and IPv4 SFM Information
  • MLD Snooping MLD Snooping Status, Groups Information and IPv6 SFM Information
  • DHCP Server, Snooping Table, Relay Statistics and Detailed Statistics
  • Security Port Security, Access Management Statistics, 802.1X, ACL Status and AAA
  • QoS QoS Statistics and QCL Status
  • IP Config IP Configuration, IP Interfaces and IP Routes
  • IP status IP Interfaces, IP Routes and ARP Table
  • DHCP server DHCP Server Mode Configuration, Excluded IP and Pool
  • NTP NTP Configuration
  • Timezone System Timezone Offset and UTC time
  • SNMP System, Trap, Communities, Users, Groups, Views and Access
  • System messages System Log Configuration
  • Ports Port Configuration
  • Aggregation Static and LACP
  • Mirroring Mirror and Mirror Port Configuration
  • Overheating protection Thermal Protection Configuration
  • Green Ethernet Port Power Savings and Port Configuration
  • DDM DDM Configuration, DDM Overview and DDM Detailed
  • PoE settings Power Over Ethernet, PoE Power Supply and PoE Port Configuration
  • PoE status Power Over Ethernet Status
  • MAC address table Aging Configuration, MAC Table Learning and Static MAC Table Configuration
  • PTP PTP Clock Configuration and PTP Status
  • VLANs Global VLAN and Port VLAN Configuration
  • Voice VLAN Voice VLAN Configuration and Voice VLAN OUI Table
  • GVRP GVRP Global and Port Configuration
  • Port insulation Port Group and Port Isolation
  • Loop Protection General Settings and Port Configuration
  • Comprehensive protocols Bridge Settings, MSTI Mapping, MSTI Priorities, CIST Ports and MSTI Ports
  • IPMC profile Profile Table and Address Entry
  • MEP Maintenance Entity Point
  • ERPS Ethernet Rapid Ring Protection Switching
  • IGMP Snooping Basic Configuration, VLAN Configuration and Port Filtering Profile
  • IPV6 MLD Snooping Basic Configuration, VLAN Configuration and Port Filtering Profile
  • LLDP LLDP Parameters and LLDP Interface Configuration
  • Users Users Configuration
  • Privilege levels Privilege Level Configuration
  • SSH SSH Configuration
  • HTTPS HTTPS Configuration
  • Port security margin System and Port Configuration
  • Access control Access Management Configuration
  • 802.1X Network Access Server Configuration
  • ACL Ports, Rate Limiters and Access Control List
  • ARP Inspection Port Configuration, VLAN Configuration, Static Table and Dynamic TableAAA RADIUS and TACACS+
  • Port Classification QoS Ingress Port Classification
  • Port policy QoS Ingress Port Policers
  • Queue policy QoS Ingress Queue Policers
  • Port planning QoS Egress Port Schedulers
  • Port shaping QoS Egress Port Shapers
  • Port tag marking QoS Egress Port Tag Remarking
  • Port DSCP QoS Port DSCP Configuration
  • DSCP-Based QoS DSCP-Based QoS Ingress Classification
  • DSCP translation DSCP translation
  • DSCP classification DSCP classification
  • QoS control list QoS Control List Configuration
  • Storm Policing Global Storm Policer Configuration
  • Ping ICMP Ping
  • Cable diagnostics Cable Status
  • Processor load CPU Load Information
  • Restarting the device Restart the Device
  • Factory settings Factory settings
  • Software update Software Upload
  • Software selection Software Image Selection
  • Configuration Download, Upload, Activate and Delete

ManufacturerUTEPO
Manufacturer codeSWITCHUTP6306S-PSB
Weight0.567 kg
