Lindy 8x8 HDMI 8K60 Matrix
The 8x8 HDMI 8K60 Matrix connects eight 8K UHD sources to eight 8K UHD displays, supporting HDMI 2.1 with 48Gbps bandwidth. It features multiple audio output options, IR control, and can be controlled via RS-232 or a web interface.
- Effortlessly switches between 8 HDMI sources and distributes to 8 outputs, supporting 8K resolution at 60Hz frequency.
- Supports advanced audio formats, including Dolby Atmos and 7.1 channel audio transmission, ensuring an immersive audio experience.
- Multiple control options are available: front panel buttons, IR remote control, RS-232, and web GUI for ease of use.
- There is built-in ARC, HDR 10, and downscaling capabilities to ensure compatibility with a variety of screen resolutions.
Features | |
|---|---|
| Product type | AV Matrix Switch |
| Model | 8x8 HDMI 8K60 Matrix |
Specifications | |
| AV interface | HDMI® |
| Interface standard | HDMI® 2.1 |
| Supported bandwidth | 48Gbps |
| Maximum resolution | 7680x4320@60Hz 4:2:0 12bit |
| HDCP support | 2.3 |
| Supported audio | HDMI® audio transmission up to 7.1CH, Coax up to 5.1CH, Stereo analog |
| IR support | 38kHz |
| CEC support | Yes |
| Serial interface | RS-232 (Female) |
| Management options | Front panel buttons, IR remote control, RS-232, web GUI |
| Special features | ARC, 8K to 1080p output downscaling, Dolby Vision, Dolby Atmos, HDR 10 |
Connectors | |
| Input | 8 x HDMI® (Female) |
| Output | 8 x HDMI® (Female), 8 x Phoenix (Female), 8 x Coax (Female) |
| Management | RS-232 (Female), RJ45 (Female), Stereo Mini-jack |
| Power supply | 5.5/2.5mm |
Physical properties | |
| Dimensions | 440x203x44.5mm (17.32x7.99x1.75in) |
| Weight | 2.94kg (6.48lb) |
| Housing | Metal |
| Working temperature | 0°C - 40°C (32°F - 104°F) |
| Storage temperature | -20°C - 60°C (-4°F - 140°F) |
| Humidity | 10-90% (non-condensing) |
| Power requirements | 24VDC 3.75A |
| MTBF | 50,000 hours |
| Color | Black |
Package contents | |
| |
www.lindy.lt
| Height | 70 mm |
| Length | 350mm |
| Weight | 3600 grams |
| Width | 500mm |
