Ubiquiti AI-Key gateway / controller

Ubiquiti AI-Key. Product colour: Steel, Enclosure material: Aluminium. Processor manufacturer: ARM, Processor family: ARM Cortex, Processor model: Cortex-A78AE. Ethernet LAN data rates: 1000 Mbit/s. Interface: Ethernet. Power consumption (max): 45 W, Input voltage: 50-57 V, Power over Ethernet (PoE) type supported: PoE++ (4PPoE)

AI Key is an advanced edge AI appliance designed to elevate your UniFi Protect security system. It enhances detection capabilities with powerful features like NeXT AI natural language search, AI alerts, speech transcription, image enhancement. Setting up the AI Key is quick and straightforward, allowing you to unlock advanced AI-driven insights that transform how you monitor and secure your environment.

AI Key works as an edge appliance by receiving smart detections from paired UniFi cameras. Traditionally, Protect cameras are only able to recognize very basic objects such as people and vehicles. AI Key takes these basic smart detections and runs them through a series of advanced AI models to provide powerful new features. While the models used by AI Key provide many useful new features, they might occasionally return inaccurate results. Over time these models will be optimized to improve their accuracy and add additional features.

Design

Product colour: Steel
Enclosure material: Aluminium

Performance

Feature: Control display unit
Feature: Built-in processor
Processor manufacturer: ARM
Processor family: ARM Cortex
Processor model: Cortex-A78AE
Internal memory: 16000 MB
Internal memory type: LPDDR5
SSD capacity: 128 GB
Detections per hour: 1000

Network

Ethernet LAN data rates: 1000 Mbit/s

Ports & interfaces

Interface: Ethernet
Ethernet LAN (RJ-45) ports: 1

Management features

Feature: Reset button

Power

Power consumption (max): 45 W
Input voltage: 50-57 V
Power over Ethernet (PoE) type supported: PoE++ (4PPoE)
Feature: Power over Ethernet (PoE)
Feature: Electrostatic Discharge (ESD) protection
Electrostatic Discharge (ESD) protection (air): 12 kV
Electrostatic Discharge (ESD) protection (contact): 8 kV
Feature: Electromagnetic (EMP) protection
Electromagnetic (EMP) protection (air): 12 kV
Electromagnetic (EMP) protection (contact): 8 kV

Weight & dimensions

Width: 134.2 mm
Depth: 131.2 mm
Height: 33.7 mm
Weight: 635 g

Operational conditions

Operating temperature (T-T): -5 - 40 °C
Operating relative humidity (H-H): 5 - 95%

Certificates

Compliance certificates: CE, Federal Communications Commission (FCC)
Certification: IC

Display

Feature: Touchscreen
Display diagonal: 3.3 cm (1.3")
