StarTech.com IDE2SAT2 interface cards / adapter

StarTech.com IDE to SATA Hard Drive or Optical Drive Adapter - 40-Pin PATA to 2.5" SATA HDD/SSD/ODD Converter - TAA. Host interface: IDE, Output interface: SATA, Connector(s): 1 x IDE (40 Pin; EIDE/PATA), 1 x SATA (7+15 pin), 1 x SP4 (4 pin). Product colour: Red, Certification: FCC, CE, TAA, REACH. Chipset: Marvell - 88SA8052, Data transfer rate (max): 0.133 Gbit/s, Logical block addressing (LBA) support: 48 bit. Width: 20 mm, Depth: 75.5 mm, Height: 23 mm. Package width: 142 mm, Package depth: 174 mm, Package height: 34 mm

Connect your SATA Hard Drive or Blu-ray/DVD/CD-ROM Drive to an IDE motherboard

The IDE2SAT2 40-pin IDE to SATA adapter enables you to connect a SATA I/II/III drive to an available IDE/ATA 33/66/100/133 motherboard port - a cost effective solution that allows you to add newer SATA drives, and keep your existing motherboard.

The IDE/SATA adapter offers a cost-effective solution for bridging the gap between a newer 2.5"/3.5"/5.25" SATA drive and older IDE motherboard port. The IDE2SAT2 also features ODD (Optical Disk Drive) support, allowing you to a add Blu-ray, DVD, or CD-ROM drives to an older IDE motherboard.

The IDE/SATA adapter is backed by a StarTech.com 2-year Warranty and free lifetime technical support.

Ports & interfaces

Host interface: IDE
Output interface: SATA
Connector(s): 1 x IDE (40 Pin; EIDE/PATA), 1 x SATA (7+15 pin), 1 x SP4 (4 pin)

Design

Feature: Internal
Product colour: Red
Certification: FCC, CE, TAA, REACH

Features

Chipset: Marvell - 88SA8052
Data transfer rate (max): 0.133 Gbit/s
Logical block addressing (LBA) support: 48 bit

Operational conditions

Operating temperature (T-T): 5 - 50 °C
Storage temperature (T-T): -25 - 80 °C
Operating relative humidity (H-H): 15 - 90%

Technical details

Compliance certificates: RoHS

Weight & dimensions

Width: 20 mm
Depth: 75.5 mm
Height: 23 mm
Weight: 29 g

Packaging data

Feature: Manual
Package width: 142 mm
Package depth: 174 mm
Package height: 34 mm
Package weight: 89 g

Logistics data

Harmonized System (HS) code: 84733020
Products per master (outer) case: 60 pc(s)
Master (outer) case width: 512 mm
Master (outer) case length: 396 mm
Master (outer) case height: 326 mm

Other features

Material: Plastic, Steel
