StarTech.com 4K50IC-EXTEND-HDMI AV extender

StarTech.com HDMI Extender Over CAT5e/CAT6, 4K 60Hz, Up to 200ft (60m), Transmitter and Receiver Kit, Power Over Cable, Compact Form Factor. Type: AV transmitter receiver, Maximum resolution: 3840 x 2160 pixels, Cable types supported: Cat5e, Cat6. Connectivity technology: Wired, USB connector type: USB Type-C. Power source type: USB, AC input voltage: 100 - 240 V, Input current: 0.3 A. Receiver dimensions (WxDxH): 40 x 67 x 23 mm, Receiver weight: 92 g, Transmitter dimensions (WxDxH): 40 x 67 x 23 mm. Package width: 150 mm, Package depth: 117 mm, Package height: 77 mm
Extend a 4K 60Hz HDMI signal over CAT6/6A cabling for distances of up to 200ft (60m) with Power over Cable
The HDMI Extender is designed to transmit visually lossless and low latency 4K 60Hz video and 7.1 channel audio up to 200 feet (60 meters) over a single network cable.
4K 60Hz Resolution
This HDMI over CAT5e extender is HDMI 2.0 compliant and supports up to 4K 60Hz resolutions, HDR, HDCP 2.2, DTS, and Dolby Digital audio. This makes it suitable for high-quality video and audio transmission over long distances.
Power-Over-Cable
The extender features Power-over-Cable (PoC) technology, allowing the included power adapter to connect only to the transmitter while providing power to both the transmitter and receiver through the CAT5e/6 cable. This feature reduces the need for additional power sources at the receiver end.
Versatile Installation Options
A point-to-point connection uses a single CAT6/5e cable and requires no drivers, software, or IP configuration, significantly reducing setup time. The HDMI extender can be mounted on a wall, ceiling, or the underside of a table using the included brackets, offering versatile professional installation options. The HDMI extender offers a longer range than HDMI cables, and Ethernet cables are easier to run in walls, behind furniture, or through cable trays. Its compact form factor makes it ideal for boardrooms, digital signage, trade shows, and classrooms.

Features

Type: AV transmitter receiver
Maximum resolution: 3840 x 2160 pixels
Cable types supported: Cat5e, Cat6
Maximum transfer distance: 60 m
Maximum refresh rate: 60 Hz
Audio output channels: 7.1 channels
Supported graphics resolutions: 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1440 x 900, 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 1920 x 1440, 2048 x 1152, 2048 x 1536 (QXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 2560 x 1920, 2560 x 2048
HDCP: Yes
Material: Metal
Rack mounting: No
HDCP version: 2.2
Product colour: Black

Ports interfaces

Connectivity technology: Wired
RJ-45 input ports: 1
RJ-45 output ports: 1
HDMI in: 1
Number of HDMI outputs: 1
HDMI version: 2.0
USB ports quantity: 1
USB connector type: USB Type-C

Power

Power source type: USB
AC input voltage: 100 - 240 V
Input current: 0.3 A
Operating voltage (transmitter): 5 V
Output current: 2 A
Operating voltage (receiver): 5 V
Power consumption (typical): 10 W
USB Power Delivery (USB PD): Yes
External power adapter: Yes

Operational conditions

Operating temperature (T-T): -20 - 60 °C
Storage temperature (T-T): -30 - 70 °C
Operating relative humidity (H-H): 0 - 90%

Weight dimensions

Receiver dimensions (WxDxH): 40 x 67 x 23 mm
Receiver weight: 92 g
Transmitter dimensions (WxDxH): 40 x 67 x 23 mm
Transmitter weight: 92 g

Packaging data

Package width: 150 mm
Package depth: 117 mm
Package height: 77 mm
Package weight: 364 g

Packaging content

AC adapter included: Yes
Included power plug types: ANZ, EU, NA, UK
Quick start guide: Yes
Mounting brackets included: Yes

Technical details

Compliance certificates: Federal Communications Commission (FCC), RoHS

Logistics data

Master (outer) case width: 430 mm
Master (outer) case length: 330 mm
Master (outer) case height: 380 mm
Products per master (outer) case: 30 pc(s)
