ROLINE OM4, LC / LC, 0.5m InfiniBand / fibre optic cable

ROLINE FO Jumper Cable 50/125µm OM4, LC/LC, Low-Loss-Connector, for Data Center 0,5m. Cable length: 0.5 m, Fibre optic type: OM4, Connector 1: LC, Connector 2: LC

• Security for the future! The OM4 fiber and connector quality with very low insertion ensure an excellent quality at very high bandwidths.


• It supports 10 Gb/s Ethernet, Fibre Channel, and OIF applications to 550 meters, extends the system cost benefits to ultra long building backbones and medium length campus backbones.


• Material and clothing in ROLINE quality


• The cable assembled with "low-loss" connectors achieve very good values for insertion loss and reflection. In comparison:

- Typical attenuation of a standard LC connector: 0.5 dB
- Typical attenuation of a low-loss LC connector: 0.15 dB

• Modal Bandwidth: 4700 MHz-km (this bandwidth is based on application-specific implementation of the EMBC requirements)


• Duplex cables with fiber type Multi-mode 50/125µm, OM4


• Color: purple

.

Features

Cable length: 0.5 m
Fibre optic type: OM4
Connector 1: LC
Connector 2: LC
Connector 1 gender: Male
Connector 2 gender: Male
Product colour: Grey, Violet, White

Sustainability

Doesn't contain: Halogen

Other features

Length: 0.5 mm
Number of optical fibres: 2

Logistics data

Harmonized System (HS) code: 85447000
