ROLINE 11.04.5957-10 USB graphics adapter

ROLINE 11.04.5957-10. USB version: 3.2 Gen 1 (3.1 Gen 1), USB connector type: USB Type-C, USB connector gender: Male. Product colour: Black. Depth: 200 mm, Weight: 19.9 g. Package width: 20 mm, Package depth: 60 mm, Package height: 20 mm

Reversible cableadapter which enables the connection between devices with USB Type-C and DisplayPort connectors

Bidirectional cableadapter - works in BOTH signal directions with USB Type-C and DisplayPort connectors

Requires the support of DisplayPort Alternate Mode on the USB Type C connection (laptop / PC / monitor)

Offers a variety of possible applications
- monitor or TV connection with DisplayPort socket to a laptop/smartphone with USB Type-C port.
- connection of an USB Type-C monitor to a device with DisplayPort output (notebook/PC...)

Plug & Play

Converter is bus powered, this makes the integration within installations easy, with no additional need for external power supplies or outlets

Max. resolution: 3840 x2160 @60Hz

Connectors: DisplayPort female and Type C Male

Performance

USB connector type: USB Type-C
USB connector gender: Male
USB connector form factor: Straight
USB version: 3.2 Gen 1 (3.1 Gen 1)
Feature: DisplayPort output
Number of displays supported: 1
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
DisplayPort version: 1.2
Maximum resolution: 3840 x 2160 pixels
Refresh rate at maximum resolution: 60 Hz
Power plug type: No plug

Design

Product colour: Black

Weight & dimensions

Depth: 200 mm
Weight: 19.9 g

Packaging data

Package width: 20 mm
Package depth: 60 mm
Package height: 20 mm
Package weight: 40 g
