LAN cable UTP 1GB / S 305M CCA wire red

Description

LAN UTP 1GB/S 305M CCA wire red cable.

• Data transmission speed: 1Gbps
• Conductor type: copper (CCA)
• AWG 23 (4 x 2 x 0.57 mm)
• Conductor construction: single wire
• Printed length counter every meter of cable
• PVC outer insulation: 5.6 mm
• HDPE insulation of conductor: 0.95 mm
• Operation up to 250 Mhz
• Packaging: cardboard box

Electrical parameters (20 degrees):

• Conductor resistance (max.):
• Rated voltage:
• Maximum current: 0.5 A
• Storage and transport temperature: 0 - 60 degrees
• Operating temperature: -20 - 75 degrees
• Operating distance: 100 m

PURPOSE: cable intended for short lengths (up to 10m) cut-off only. For use only in installations without Fluke certification requirement (EN 50173).
