HDMI Switch - LINDY 4 Port HDMI 18G Switch 2.0 3840x2160@60Hz Audio
Product reference:
14-4002888382496
Supports 4 HDMI 2.0 sources with a maximum resolution of 3840x2160@60Hz and 18Gbps bandwidth. The device has separate audio outputs for stereo and optical audio, as well as automatic switching of active ports.
HDMI Switch - LINDY 4 Port HDMI 18G Switch 2.0 3840x2160@60Hz Audio
Product reference:
14-4002888382496
Supports 4 HDMI 2.0 sources with a maximum resolution of 3840x2160@60Hz and 18Gbps bandwidth. The device has separate audio outputs for stereo and optical audio, as well as automatic switching of active ports.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
LINDY 4 Port HDMI 18G Switch 2.0 3840x2160@60Hz Audio
Facilitates 4 HDMI 2.0 sources with maximum 3840x2160@60Hz resolution and 18Gbps bandwidth. Offers separate audio outputs for stereo and optical audio, as well as automatic switching of active ports.
- Facilitates 4 HDMI inputs with maximum 3840x2160@60Hz resolution for stunning visuals.
- Offers audio pass-through and separate audio ports for a variety of audio options.
- Automatic switching of active ports and IR support for convenient control.
- Compact metal body with lightweight design, perfect for any configuration.
Features | |
|---|---|
| Product type | HDMI Switch |
| Model | 4 Port HDMI 18G Switch |
Specifications | |
| AV interface | HDMI® |
| Interface standard | HDMI® 2.0 |
| Supported bandwidth | 18Gbps |
| Maximum resolution | 3840x2160@60Hz 4:4:4 8bit |
| HDCP support | 2.2 |
| Supported audio | Audio bandwidth, Analog 2CH, Up to 5.1CH (Optical) |
| Separate audio ports | Stereo (3.5mm), Toslink (Optical) |
| IR support | 38kHz |
| CEC support | Throughput |
| Serial interface | RS232 (3.5mm) |
| Special features | Audio EDID control, Automatic switching of active ports |
Connectors | |
| Entrance | 4 x HDMI® Type A (Female) |
| Exit | HDMI® Type A (Female), 3.5mm (Female) |
| Management | RS232 (3.5mm), AND (3.5mm) |
| Power supply | 5.5/2.1mm DC plug |
Physical properties | |
| Dimensions (approximate) | 180x85x11.6mm (7.09x3.35x0.46in) |
| Housing material | Metal |
| Net weight | 0.563kg (1.24lb) |
| Working temperature | 0°C - 40°C (32°F - 104°F) |
| Storage temperature | -20°C - 60°C (-4°F - 140°F) |
| Humidity | 20-90% RH (non-condensing) |
| Power requirements | 5VDC 1A |
| Color | Black |
Additional information | |
| Packaging type | Cardboard box |
| Package dimensions | 248x55x183mm (9.76x2.17x7.2in) |
| Total weight | 0.682kg (1.5lb) |
| Product compliance | CE, FCC, RoHS REACH |
www.lindy.lt
| Height | 55 mm |
| Length | 248 mm |
| Weight | 682 grams |
| Width | 183 mm |
