HDMI Matrix Switch - Lindy 38152 4K60 4×4, 4K 60 Hz, 18 Gbps, HDCP 2.2, Black
Product reference:
14-4002888381529
The 4×4 HDMI 2.0 matrix switcher routes four HDMI sources to four displays, supports resolutions up to 4096 × 2160 at 60 Hz, 18 Gbps data rates, HDCP 2.2 and audio pass-through. The device can be controlled via infrared remote control, buttons or RS-232; it also provides EDID management and a robust black metal housing construction (220 × 105 × 19 mm).
HDMI Matrix Switch - Lindy 38152 4K60 4×4, 4K 60 Hz, 18 Gbps, HDCP 2.2, Black
Product reference:
14-4002888381529
The 4×4 HDMI 2.0 matrix switcher routes four HDMI sources to four displays, supports resolutions up to 4096 × 2160 at 60 Hz, 18 Gbps data rates, HDCP 2.2 and audio pass-through. The device can be controlled via infrared remote control, buttons or RS-232; it also provides EDID management and a robust black metal housing construction (220 × 105 × 19 mm).
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
Lindy 38152 4K60 HDMI 4×4 matrix switcher
The 4×4 HDMI 2.0 matrix switch allows four HDMI sources to be independently connected to four displays. Supports resolutions up to 4096 × 2160 at 60 Hz, 18 Gbps bandwidth, HDCP 2.2 and HDMI audio pass-through. The device can be controlled via IR remote control, buttons or via RS-232. EDID control is also provided. The black metal housing measures 220 × 105 × 19 mm.
- 4×4 HDMI matrix switcher for independently routing four HDMI sources to four displays
- Supports HDMI 2.0, 18 Gbps bandwidth and up to 4K resolution at 60 Hz, 4:4:4, 8-bit color
- HDCP 2.2 compliant and features EDID management for reliable compatibility between sources and displays
- Convenient control via front panel buttons, IR remote control or RS-232
Product information | |
|---|---|
| Product type | HDMI 4×4 matrix switcher |
| Brand | Lindy |
| Model | 38152 |
| Function | Independently routes four HDMI sources to four HDMI displays |
| Color | Black |
Technical specifications | |
| HDMI standard | HDMI 2.0 |
| Highest resolution | 4096 × 2160 at 60 Hz, 4:4:4, 8-bit color |
| Throughput | 18Gbps |
| HDCP | HDCP 2.2 |
| Sound | HDMI audio transmission |
| EDID | EDID control |
| IR frequency | 30-60 kHz |
Connections and control | |
| HDMI inputs | 4 × HDMI female |
| HDMI outputs | 4 × HDMI female |
| Management methods | Front panel buttons, IR remote control and RS-232 |
| Control connector | USB Micro-B female |
| Power connector | 5.5/2.1mm DC jack |
Physical specifications | |
| 220 × 105 × 19 mm (width × height × depth) | |
| Weight | 0.535 kg |
| Housing material | Metal |
| Operating temperature | from 0°C to 40°C |
| Storage temperature | from −20 °C to 60 °C |
| Operating humidity | 20-90%, non-condensing |
| Power requirements | 12V DC, 2.5A |
Included accessories | |
| Complete set | HDMI matrix switcher, IR remote control, multi-country power supply with EU, UK, US and Australian adapters, and user manual |
Safety information | |
| Safety warning | Use only to route compatible HDMI audio and video signals. Use the supplied power supply, protect the device from moisture, and ensure adequate ventilation. Unplug the device from the power source before connecting or disconnecting cables. |
| Height | 60mm |
| Length | 300mm |
| Weight | 1432 grams |
| Width | 240mm |
