Splits HDMI® signals to four displays with a maximum resolution of 3840x2160@60Hz. Supports HDMI® 1.4 and 10.2G bandwidth.
Splits HDMI® signals to four displays with a maximum resolution of 3840x2160@60Hz. Supports HDMI® 1.4 and 10.2G bandwidth.


Splits HDMI® signals to four displays with a maximum resolution of 3840x2160@60Hz. Supports HDMI® 1.4 and 10.2G bandwidth.
Guarantee
24 month
Delivery from Lithuania in
2 - 3
business days
Distributes HDMI® signals to four displays with a maximum resolution of 3840x2160@60Hz. Supports HDMI® 1.4 and 10.2G bandwidth.
Features | |
|---|---|
| Product type | HDMI Splitter |
| Model | 4 Port HDMI 10.2G Splitter |
Specifications | |
| AV interface | HDMI® |
| Interface standard | HDMI® 1.4 |
| Supported bandwidth | 10.2G |
| Maximum resolution | 3840x2160@60Hz 4:2:0 8bit |
| HDCP support | 1.4 |
| Supported audio | Transmission |
Connectors | |
| Entrance | HDMI® Type A (Female) |
| Exit | 4 x HDMI® Type A (Female) |
| Power supply | 5.5/2.1mm |
Physical properties | |
| Dimensions (WxHxD) | 146x71x25mm (5.75x2.8x0.98in) |
| Housing material | Metal |
| Net weight | 0.407kg (0.9lb) |
| Operating temperature | 0°C - 40°C (32°F - 104°F) |
| Storage temperature | -20°C - 60°C (-4°F - 140°F) |
| Humidity | 20~90% RH (non-condensing) |
| Power requirements | 5VDC 1A |
| Color | Black |
Additional information | |
| Packaging type | Cardboard box |
| Package dimensions | 215x150x55mm (8.46x5.91x2.17in) |
| Total weight | 0.54kg (1.19lb) |
| Product compliance | CE, FCC, RoHS REACH |
Safety warning | |
| Use the product only for its intended purpose. | |
| Height | 70mm |
| Length | 220mm |
| Weight | 538 grams |
| Width | 130 mm |
