HDMI Splitter Extender - LINDY Cat.6 4 Port HDMI 4K30 and IR Extender 3840x2160@30Hz 70 m
Product reference:
14-4002888381550
Extend and distribute HDMI and IR signals to up to 4 displays at a distance of up to 70 m, with a maximum resolution of 3840x2160@30Hz. The device supports HDCP 1.4, 7.1 audio transmission and has a Power over Cable function.
HDMI Splitter Extender - LINDY Cat.6 4 Port HDMI 4K30 and IR Extender 3840x2160@30Hz 70 m
Product reference:
14-4002888381550
Extend and distribute HDMI and IR signals to up to 4 displays at a distance of up to 70 m, with a maximum resolution of 3840x2160@30Hz. The device supports HDCP 1.4, 7.1 audio transmission and has a Power over Cable function.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
LINDY Cat.6 4 Port HDMI 4K30 and IR Extender 3840x2160@30Hz 70 m
Extend and distribute HDMI and IR signals to up to 4 displays at distances of up to 70 m, with a maximum resolution of 3840x2160@30Hz. Supports HDCP 1.4, 7.1 audio transmission and has a Power over Cable function.
- Supports 4K resolution up to 3840x2160@30Hz with maximum distances up to 70 m (229.66 ft).
- There is a Power over Cable (PoC) function, which allows for convenient installation without additional power supplies.
- The kit includes 4 receivers and IR support, providing flexible remote control options.
- Compatible with HDMI 1.4 and supports up to 7.1 channel audio transmission.
Features | |
|---|---|
| Product type | AV splitter |
| Model | 70m Cat.6 4 Port HDMI 4K30 IR Splitter Extender |
Specifications | |
| AV interface | HDMI® |
| Interface standard | HDMI 1.4 |
| Supported bandwidth | 10.2Gbps |
| Maximum distance | 70m (229.66 feet) at 1920x1080@60Hz; 40m (131.23 feet) at 3840x2160@30Hz |
| HDCP support | HDCP 1.4 |
| EDID transmission | Preset, cloning function |
| IR support | 20-60 kHz |
| Transmission medium | 1 x Cat.6 (for each receiver) |
Connectors | |
| Sender input | HDMI® (Female) |
| Sender output | 4 x RJ45 (Female), HDMI® (Female), IR (Female) |
| Receiver input | RJ45 (Female), AND (Female) |
| Receiver output | HDMI® (Female) |
| Power supply | 5.5/2.1mm DC socket |
Physical properties | |
| Dimensions (sender) | 210x83x17mm (8.27x3.27x0.67in) |
| Dimensions (receiver) | 79x68x17mm (3.11x2.68x0.67in) for each device |
| Housing | Metal |
| Net weight (shipper) | 0.443kg (0.98lb) |
| Net weight (receiver) | 0.131kg (0.29lb) for each device |
| Working temperature | 0°C - 40°C (32°F - 104°F) |
| Storage temperature | -20°C - 60°C (-4°F - 140°F) |
| Humidity | 20 - 90% RH (non-condensing) |
| Power requirements | 12VDC 3A |
| Color | Black |
Package contents | |
| Splitter sender unit, 4 x receiver unit, IR transmitter cable, 4 x IR receiver cable, 2 x mounting brackets with screws, multi-country power supply (EU, JK, US and AUS), Lindy manual | |
www.lindy.lt
| Height | 90 mm |
| Length | 265 mm |
| Weight | 1529 grams |
| Width | 200mm |
