HDMI Splitter - 70m Cat.6 2 Ports 4K@60Hz IR Support
Product reference:
14-4002888383851
HDMI splitter - 70m Cat.6, 2 ports, 4K@60Hz IR support. Extends 4K@60Hz resolution up to 70m using Cat.6 cable and includes two receivers. Supports HDCP 2.2 and has IR function for remote control.
HDMI Splitter - 70m Cat.6 2 Ports 4K@60Hz IR Support
Product reference:
14-4002888383851
HDMI splitter - 70m Cat.6, 2 ports, 4K@60Hz IR support. Extends 4K@60Hz resolution up to 70m using Cat.6 cable and includes two receivers. Supports HDCP 2.2 and has IR function for remote control.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
70M Cat.6 2 Port HDMI 4K60 IR Splitter Extender
Extends the resolution of 4K@60Hz to 70m using Cat.6 cable and includes two receivers. Supports HDCP 2.2 and has IR support for remote control function.
- Supports 4K resolution 60Hz over the maximum distance 70m (229.66ft).
- There is a Power over Cable (PoC) function that simplifies installation.
- 2 receivers and multiple IR cables included for universal connectivity.
- Complies with CE, UKCA, FCC, RoHS and REACH standards, ensuring safety and quality.
Features | |
|---|---|
| Product type | HDMI Splitter Extender |
| Model | 70m Cat.6 2 Port HDMI 4K60 IR Splitter Extender |
Specifications | |
| AV interface | HDMI® |
| Supported bandwidth | 18Gbps (HDMI 2.0 specifications) |
| Maximum distance | 70m (229.66ft) |
| Maximum resolution | 3840x2160@60Hz 4:4:4 8bit |
| HDCP support | 2.2 |
| EDID control | 4K60, downscaling to Full HD, copying from loop-out port, is planned |
| Supported audio | LPCM 2CH, up to 5.1 (copying EDID from loop out port) |
| IR support | 20-60KHz |
| Transmission medium | Cat.6 |
| Chipset | GSV2006 GSV5100 |
| Special features | Power over Cable (PoC) |
Connectors | |
| Send input | HDMI® Type A (Female) |
| Send output | 2 x RJ-45 (Female), HDMI® Type A (Female), 3.5mm IR (Female) |
| Receiver input | RJ-45 (Female), 3.5mm AND (Female) |
| Receiver output | HDMI® Type A (Female) |
| Power supply | 5.5/2.1mm |
Physical properties | |
| Dimensions (sender) | 154x103x23mm (6.06x4.06x0.91in) |
| Dimensions (receiver) | 100x88x23mm (3.94x3.46x0.91in) |
| Housing | Metal |
| Net weight (shipper) | 0.263kg (0.58lb) |
| Net weight (receiver) | 0.199kg (0.44lb) |
| Working temperature | 0°C - 50°C (32°F - 122°F) |
| Storage temperature | -10°C - 80°C (14°F - 176°F) |
| Humidity | 5 - 90% RH (non-condensing) |
| Power requirements | 12VDC 2A |
| Color | Black |
Miscellaneous | |
| Packaging type | Cardboard box |
| Package dimensions | 292x238x55mm (11.5x9.37x5.47in) |
| Total weight | 1.18kg (2.6lb) |
| Product compliance | CE, UKCA, FCC, RoHS, REACH |
www.lindy.lt
| Height | 238 mm |
| Length | 292 mm |
| Weight | 1180g |
| Width | 55 mm |
