Digitus DN-95205 PoE adapter

Digitus Gigabit Ethernet PoE+ Splitter, 802.3at, 24 W. Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3at. Product colour: Black, LED indicators: PoE, Power protection features: Short circuit. Power over Ethernet (PoE) voltage: 12 V, Output power: 24 W, Input voltage: 34 - 57 V. Weight: 80 g, Dimensions (WxDxH): 55 x 80 x 23 mm. Number of products included: 1 pc(s)

Integrates Power over Ethernet technology to older non PoE network devices

- Gigabit Ethernet Speed
- Fanless design ensures a quiet operation
- Requires no external power supply unit
- Adjustable output 5V/2A , 9V/2A, 12V/2A
- Support 5.5mm and 3.5mm power jack

The DIGITUS PoE Splitter provide data and power via a single Ethernet Cable to devices, which are not supporting Power over Ethernet. Just connect the input of the Splitter to a PoE Switch or a PoE Injector and the output side to a non-PoE network device such as an access point, IP Phone or a Camera to provide Power and Data. The Extender is self powered by PoE, so there is no additional power supply needed. The output voltage can be regulated via a dip switch to 5V , 9V or 12V. So this Splitter expand your network where you wish to place network device where are no power outlets available.

Network

Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Power over Ethernet (PoE)
Networking standards: IEEE 802.3at

Features

Product colour: Black
LED indicators: PoE
Power protection features: Short circuit

Ports & interfaces

Ethernet LAN (RJ-45) ports: 2
Feature: DC-in jack

Power

Power over Ethernet (PoE) voltage: 12 V
Output power: 24 W
Input voltage: 34 - 57 V
Output current: 2 A

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Weight & dimensions

Weight: 80 g
Dimensions (WxDxH): 55 x 80 x 23 mm

Packaging content

Number of products included: 1 pc(s)
Feature: AC adapter included
Feature: Power cord included
Feature: Manual

Packaging data

Package width: 80 mm
Package depth: 153 mm
Package height: 25 mm
Package weight: 130 g
Package volume: 306 cm³

Logistics data

UK Trade Tariff code: 85176200
Harmonized System (HS) code: 85044095
Country of origin: China
