Digitus DN-95117 network switch

Digitus 24 Port 10G Ethernet PoE+ Injector, 802.3at, 370 W. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex, Networking standards: IEEE 802.3af. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Minimization of the cabling costs for PoE-capable devices
- 24 10G ports with PoE+ support
- 370 watt performance with up to 30 watts per port
- Compatible with the IEEE802.3at standards
- Automatic surge protection
- Supports bandwidth up to 10Gbps
The DIGITUS® DN-95117 is an 24 port 10G PoE+ mid-span hub (PoE injector). It offers 24 input ports for data and 24 output ports which make data and PoE available. Each PoE-port supports connected devices in accordance with the IEEE802.3af and IEEE802.3at PoE standard with 15.4 watts and/or 30 watts, such as PoE access points, PoE IP-telephones or PoE IP cameras, for example. The switch makes available a maximum budget of 370 watts for all ports and maximum budget of 30 watts per port.

Ports interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: AC-in jack

Network

Networking standards: IEEE 802.3af
Feature: Full duplex
Feature: Auto MDI/MDI-X

Design

Feature: Rack mounting
Form factor: 1U
Product colour: Grey
LED indicators: Power
Feature: On/off switch

Performance

Feature: Plug and Play
Mean time between failures (MTBF): 100000 h

Power

AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Input current: 4.5 A
Power consumption (max): 270 W
Feature: Surge protection
Power protection features: Overload, Short circuit

Power over Ethernet (PoE)

Feature: Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 24
Power over Ethernet (PoE) voltage range: 1.2 - 3.6 V
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 370 W

Other features

Ethernet interface type: Gigabit Ethernet

Operational conditions

Operating temperature (T-T): -10 - 45 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 95%

Weight dimensions

Width: 345 mm
Depth: 440 mm
Height: 45 mm
Weight: 4.39 kg

Packaging content

Cables included: AC
Feature: Quick start guide

Packaging data

Package type: Box
Package width: 405 mm
Package depth: 505 mm
Package height: 95 mm
Package volume: 19429.9 cm³
Package weight: 5.33 kg

Logistics data

UK Trade Tariff code: 85176200
Country of origin: China
Harmonized System (HS) code: 85176990
