Digitus DN-93838 wire connector

Digitus CAT 8.1 field connector, shielded, tool-free mounting connection. Connector(s): RJ-45, Product colour: Silver, Yellow, Connector gender: Male. Quantity per pack: 1 pc(s), Package width: 20 mm, Package depth: 40 mm

25/40GBase-T transmission speed in permanent link up to 24 m and channel link up to 30 m

- High-speed transmission - Supports 25/40GBase-T with a bandwidth of 2000 MHz for ultra-fast networks
- Excellent shielding - The 360° shield contact minimizes interference and guarantees a stable connection
- Tool-free installation - field connector enables quick and easy installation without special tools
- Application area - Ideal for data centers, industry, building cabling and telecommunications

The DIGITUS® CAT 8.1 field connector with tool-free installation connection, which impresses with its future-oriented standards and high-end quality for your network. The field connector is suitable for patch cable installation with solid and stranded conductor cables. It conforms to category 8.1 / 25/40GBase-T ISO/IEC 11801, IEC 60603-7-81. The robust metal housing ensures long-lasting, stable connections. The quick assembly without special tools makes this field connector the ideal choice for installation, repair and maintenance.

Features

Connector(s): RJ-45
Connector gender: Male
Connector form factor: Straight
Product colour: Silver, Yellow
Cable standard: Cat8.1
Connector contacts plating: Nickel/Gold
Feature: Connector shielding
Power over Ethernet (PoE) type supported: PoE++ (4PPoE)
Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Dielectric strength: 1000 V
Insertion force: 30 N

Operational conditions

Operating temperature (T-T): -20 - 70 °C

Packaging data

Quantity per pack: 1 pc(s)
Package width: 20 mm
Package depth: 40 mm
Package height: 10 mm
Package weight: 20 g

Technical details

Connector material: Phosphor bronze
Housing material: Zinc
