Digitus DN-651111 network splitter

Digitus Industrial Gigabit PoE++ Splitter, 802.3bt. Networking standards: IEEE 802.3bt, Cabling technology: 10/100/1000Base-T(X), Product colour: Black. Width: 103.5 mm, Depth: 81.5 mm, Height: 32 mm. Package width: 65 mm, Package depth: 215 mm, Package height: 65 mm. Output voltage: 12 - 48 V, Output power: 55 W. Country of origin: Taiwan, Master (outer) case width: 560 mm, Master (outer) case length: 350 mm

- Gigabit Splitter with up to 95W PoE feed
- Flexibly adjustable output voltage: 12VDC, 16VDC, 24VDC, 48VDC
- Gigabit data output for network connection

The DIGITUS® Industrial Gigabit PoE Splitter is designed for harsh environments, in which it is exposed to moisture, temperature variations and vibrations. With a temperature range of -40°C to 75°C, the Industrial Gigabit PoE Splitter can be used under the most adverse conditions. It ensures a constant availability in highly sensitive areas such as transport, production, traffic and safety monitoring. The simple plug-and-play system allows a fast integration of the Industrial Gigabit PoE Splitter into the respective environment. The DIGITUS® DN-651111 is an unmanaged Plug & Play Industrial Gigabit PoE Splitter in a rugged IP30 protected aluminum housing. The Gigabit connectivity, as well as the selectable voltage that can be provided for non-PoE compatible devices, make the Industrial Gigabit PoE Splitter a flexible, cost-effective solution for the industrial environment. The supply voltage can be selected in the range of 12VDC, 16VDC, 24VDC or 48VDC. The IEEE802.3bt standard allows PoE feed of up to 95W. Two parallel current outputs are provided for terminal devices.

Features

Networking standards: IEEE 802.3bt
Cabling technology: 10/100/1000Base-T(X)
Product colour: Black
Housing material: Metal
International Protection (IP) code: IP30
LED indicators: Yes
Feature: Auto MDI/MDI-X
Feature: Plug and Play

Ports & interfaces

RJ-45 input ports: 1
RJ-45 output ports: 1

Operational conditions

Operating temperature (T-T): -40 - 75 °C

Weight & dimensions

Width: 103.5 mm
Depth: 81.5 mm
Height: 32 mm
Weight: 150 g

Packaging content

Feature: Quick installation guide

Packaging data

Package width: 65 mm
Package depth: 215 mm
Package height: 65 mm
Package weight: 437.5 g
Package volume: 2305.88 cm³

Power

Output voltage: 12 - 48 V
Output power: 55 W

Logistics data

UK Trade Tariff code: 85176200
Country of origin: Taiwan
Master (outer) case width: 560 mm
Master (outer) case length: 350 mm
Master (outer) case height: 240 mm
Master (outer) case gross weight: 7 kg
Master (outer) case volume: 47040 cm³
Products per master (outer) case: 16 pc(s)
