Digitus DA-70466 video switch

Digitus 4K HDMI EDID Emulator. Video port type: HDMI, Video in: HDMI, Video out: HDMI. Product colour: Black, Maximum resolution: 3840 x 2160 pixels, HD type: 4K Ultra HD. Width: 20 mm, Depth: 44 mm, Height: 13 mm. Package width: 75 mm, Package depth: 130 mm, Package weight: 167 g. Quantity per pack: 1 pc(s)

Emulates the EDID data for connected HDMI screens/monitors/TVs and solves possible transmission problems with the communicating devices (monitor, signal source)

- Emulates HDMI EDID (Extended Display Identification Data) information
- Solves possible transmission problems with the communicating devices (monitor, signal source), for example, at different resolutions, formats, etc.
- Has preset EDID data (resolutions/timings)
- Clone function - allows you to read and clone the EDID data of a connected TV/monitor/screen
- Supports resolutions up to UHD 4K2K / 60Hz
- HDCP pass-through
- Supports HDR for UHD and FHD resolution 4K/60Hz HDR 8-bit YCbCr 4:4:4; 4K/30Hz HDR 12-bit YCbCr 4:4:4

The Digitus 4K HDMI EDID Emulator continuously emulates a connected HDMI monitor so that the signal source does not change or disconnect your signal even when the connection is interrupted. It has preset EDID data (resolutions/timings), which can be found in the user manual. If EDID data of an individual monitor/display are missing, they can be read and cloned quickly and easily by means of the practical clone function. The emulator supports resolutions up to UHD 4K2K/60 Hz. The emulator offers the ideal solution for applications with HDMI extenders, splitters, switches or converters.

Ports & interfaces

Video port type: HDMI
HDMI ports quantity: 2
Video in: HDMI
Video out: HDMI

Features

Product colour: Black
Feature: HDCP
Maximum resolution: 3840 x 2160 pixels
HD type: 4K Ultra HD

Weight & dimensions

Width: 20 mm
Depth: 44 mm
Height: 13 mm
Weight: 15 g

Packaging data

Package width: 75 mm
Package depth: 130 mm
Package weight: 167 g
Package volume: 224.25 cm³

Packaging content

Quantity per pack: 1 pc(s)

Logistics data

UK Trade Tariff code: 84718000
Harmonized System (HS) code: 85176990
Country of origin: Taiwan
