DeLOCK 89437 network antenna

DeLOCK 89437. Antenna gain level (max): 2 dBi, Frequency band: 2.4 - 2.4835 / 5.15 - 5.7250 GHz, Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11n. Antenna type: Omni-directional antenna, Antenna connector type: SMA. Width: 108 mm, Diameter: 1 cm

This WLAN antenna can be connected to an SMA port, in order to receive or send signals.

- Connector: SMA plug
- With flexible joint, rotatable
- Frequency range: 2.4000 ~ 2.4835 GHz,
5.1500 ~ 5.7250 GHz
- Gain: 1.5 dBi @ 2.5 GHz
2.1 dBi @ 5.7 GHz
- Impedance: 50 Ohm
- VSWR: 2.0 max.
- Operating temperature: -20 °C ~ 65 °C
- Length with flexible joint ca. 108 mm, without flexible joint ca. 82.5 mm
- Diameter: 7.8 mm (Ø peak)
10.0 mm (Ø SMA)

Performance

Frequency band: 2.4 - 2.4835 / 5.15 - 5.7250 GHz
Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11n
Antenna gain (2.4 GHz): 2.5 dBi
Antenna gain (5 GHz): 5.7 dBi
Impedance: 50 Ω
Antenna gain level (max): 2 dBi

Features

Antenna type: Omni-directional antenna
Antenna connector type: SMA

Operational conditions

Operating temperature (T-T): -20 - 65 °C

Weight & dimensions

Width: 108 mm
Diameter: 1 cm

Logistics data

Harmonized System (HS) code: 85177100
