DeLOCK 12606 network antenna

DeLOCK 12606. Antenna gain level (max): 3 dBi, Frequency band: 0.698 - 0.791, 0.824 - 0.96, 1.42 - 1.52, 1.75 - 2.17, 2.45 - 2.65, 3.48 - 4.2, 4.4 - 4.9 GHz, Impedance: 50 Ω. Antenna type: Omni-directional antenna, Antenna connector type: SMA, Connector gender: Female. Width: 33.2 mm, Depth: 6.17 mm, Height: 156.2 mm. Package type: Box. Quantity per pack: 1 pc(s)
This 5G LTE antenna by Delock allows the usage of different 5G LTE bands inside. It is completely compatible to GSM, UMTS, LTE, ZigBee, Z-Wave, NB-IoT, WLAN 2.4 GHz, Bluetooth, ISM, DECT and LoRa.
5G the new mobile radio standard
5G unlike its predecessors LTE (4G) and UMTS (3G) will use more and wider frequency spectrums. The 5G standard promises more throughput, capacity and low latency.

Performance

Frequency band: 0.698 - 0.791, 0.824 - 0.96, 1.42 - 1.52, 1.75 - 2.17, 2.45 - 2.65, 3.48 - 4.2, 4.4 - 4.9 GHz
Impedance: 50 Ω
Antenna gain level (max): 3 dBi

Features

Antenna type: Omni-directional antenna
Antenna connector type: SMA
Connector gender: Female
Polarization: Vertical polarization
Voltage Standing Wave Ratio (VSWR): 3 - 5
Product colour: Black
Housing material: Acrylonitrile butadiene styrene (ABS)

Operational conditions

Operating temperature (T-T): -10 - 55 °C

Weight dimensions

Width: 33.2 mm
Depth: 6.17 mm
Height: 156.2 mm

Packaging data

Package type: Box

Packaging content

Quantity per pack: 1 pc(s)
