DeLOCK 12433 network antenna
Product reference:
29-4043619124336
DeLOCK 12433, 6.5 dBi, 50 Ω, 360°, 60°, Omni-directional antenna, SMA
DeLOCK 12433 network antenna
Product reference:
29-4043619124336
DeLOCK 12433, 6.5 dBi, 50 Ω, 360°, 60°, Omni-directional antenna, SMA
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
5 - 10
business days
DeLOCK 12433. Antenna gain level (max): 6.5 dBi, Impedance: 50 Ω, Horizontal beam width: 360°. Antenna type: Omni-directional antenna, Antenna connector type: SMA, Polarization: Vertical polarization. Width: 210 mm, Depth: 295 mm, Height: 63 mm
This antenna by Delock allows the usage of different LTE, GSM and UMTS bands indoors and outdoors. It is completely compatible to Bluetooth, WLAN 2.4 GHz, ZigBee, DECT, Z-Wave and LoRa 868 MHz / 915 MHz.
Performance
Impedance: 50 Ω
Horizontal beam width: 360°
Vertical beam width: 60°
Antenna gain level (max): 6.5 dBi
Features
Antenna type: Omni-directional antenna
Antenna connector type: SMA
Polarization: Vertical polarization
Voltage Standing Wave Ratio (VSWR): 2.0
Product colour: White
Cable type: RG-174
Operational conditions
Operating temperature (T-T): -40 - 70 °C
Weight dimensions
Width: 210 mm
Depth: 295 mm
Height: 63 mm
Diameter: 2.7 cm
Weight: 120 g
Logistics data
Harmonized System (HS) code: 85177100
| Manufacturer code | 12433 |
| Weight | 0.168 kg |
