CABLE DISPLAY PORT 1M / ANTHRA 36481 LINDY
Product reference:
2-4002888364812
CABLE DISPLAY PORT 1M / ANTHRA 36481 LINDY
Product reference:
2-4002888364812
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Lithuania in
3 - 5
business days
Not available
From the Lines cable connectivity concept developed by Lindy, Anthra Line DisplayPort cables are the professional choice for high performance connections in commercial AV and IT installations.
Anthra Line DisplayPort cables are premium connections that feature triple shielded with 28AWG tinned copper conductors for performance and corrosion resistance. High quality 24K gold plated contacts and connectors maintain optimal signal integrity and maximum reliability.
UHD resolutions up to 8K 7680x4320@60Hz 4:2:2 8bit, including 4K 4096x2160@144Hz 4:2:2 10bit and HDCP are supported. DisplayPort 1.4 technology and DisplayPort compliance certification ensures compatibility with all DisplayPort enabled devices.
Anthra Line DisplayPort cables are available in lengths from 0.5m to 5m.
- Professional choice DisplayPort 1.4 cable for commercial and high performance AV and IT installations
- Supports UHD resolutions up to 8K 7680x4320@60Hz 4:2:2 8bit including 4K 4096x2160@144Hz 4:2:2 10bit
- Robust ABS housing 24K gold plated connectors and contacts
- Triple shielded cable, corrosion resistant tinned copper 28AWG conductors
- DisplayPort 1.4, 32.4Gbps; 10 year warranty
| AWG wire size | 28 |
| Bend radius (min) | 58.4 mm |
| Cable diameter | 7.3 mm |
| Cable length | 1 m |
| Cable material | Tinned copper |
| Cable shielding | Copper |
| Cable type | Round cable |
| Certification | RoHS, REACH, UL |
| Colour sampling | 4:2:2 |
| Connector 1 | DisplayPort |
| Connector 1 dimensions (WxDxH) | 21 x 38.9 x 13.6 mm |
| Connector 1 form factor | Straight |
| Connector 1 gender | Male |
| Connector 2 | DisplayPort |
| Connector 2 dimensions (WxDxH) | 21 x 38.9 x 13.6 mm |
| Connector 2 form factor | Straight |
| Connector 2 gender | Male |
| Connector contacts plating | Gold |
| Connector housing material | Acrylonitrile butadiene styrene (ABS) |
| Connector material | Gold |
| Contact material | Phosphor bronze |
| Data transfer rate | 32.4 Gbit/s |
| DisplayPort version | 1.4 |
| Harmonized System (HS) code | 84733080 |
| Jacket material | Polyvinyl chloride (PVC) |
| Maximum refresh rate | 60 Hz |
| Maximum resolution | 7680 x 4320 pixels |
| Nominal attenuation | 100MHz-450MHz 5.1dB, 450MHz-8100MHz 33.28dB |
| Operating temperature (T-T) | -20 - 80 °C |
| Package type | Polybag |
| Plug and Play | Yes |
| Product colour | Black/Grey |
| Quantity per pack | 1 pc(s) |
| Storage temperature (T-T) | -25 - 85 °C |
| Summary | Lindy 1m DisplayPort 1.4 Cable, Anthra Line. Cable length: 1 m, Connector 1: DisplayPort, Connector 2: DisplayPort. Certification: RoHS, REACH, UL. Cable diameter: 7.3 mm, Connector 1 dimensions (WxDxH): 21 x 38.9 x 13.6 mm, Connector 2 dimensions (WxDxH): 21 x 38.9 x 13.6 mm. Package type: Polybag. Quantity per pack: 1 pc(s) |
| Supported graphics resolutions | 4096 x 2160/7680 x 4320 |
| Unit Box Height | 0.025 |
| Unit Box Length | 0.145 |
| Unit Box Width | 0.145 |
| Unit Calculated Volume | 0.0005256 cubm |
| Unit Calculated Weight | 0.09 kg |
| Units per Shipping Box | 1 |
| Vendor Homepage | https://www.lindy.co.uk/cables-adapters-c1/audio-video-c107/1m-displayport-1-4-cable-anthra-line-p11070 |
