BTR NETCOM 130863-E wire connector

BTR NETCOM 130863-E. Product colour: Multicolour, Connector form factor: Straight, AWG wire size: 22/1. Quantity per pack: 1 pc(s)
- for connecting/extending data cables up to Cat.7A
- class E to ISO/IEC 11801 Ed.2.2:2011-06 is complied with in combination with Cat.6, Cat.6A, Cat.7 and Cat.7A cables and Cat.6 connectors
- connection of data lines AWG 26/1 to 22/1 (solid wire)
- cable feed from one or two sides
- cable sharing, i.e. splitting one 8-wire cable into two 4-wire cables (one cable tie required each on input and output side)
- fully shielded metal housing
- strain relief and separate captive 360° shield connection
- 2 bore holes for wall mounting

Features

Connector form factor: Straight
Product colour: Multicolour
AWG wire size: 22/1

Operational conditions

Operating temperature (T-T): -25 - 85 °C
Storage temperature (T-T): -25 - 85 °C

Packaging data

Quantity per pack: 1 pc(s)
