AV Extender - LINDY HDMI 4K60 HDBaseT Extender 100m IR RS-232 PoC
Product reference:
14-4002888383400
Extends HDMI resolution up to 100m via HDBaseT, supporting 4K60 and audio transmission. Features include IR support, RS-232 control, and Power over Cable (PoC).
AV Extender - LINDY HDMI 4K60 HDBaseT Extender 100m IR RS-232 PoC
Product reference:
14-4002888383400
Extends HDMI resolution up to 100m via HDBaseT, supporting 4K60 and audio transmission. Features include IR support, RS-232 control, and Power over Cable (PoC).
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
LINDY HDMI 4K60 HDBaseT Extender 100 m AND RS-232 PoC
Extends HDMI resolution up to 100m via HDBaseT, supporting 4K60 and audio transmission. Features include IR support, RS-232 control, and power over cable (PoC).
- Supports 4K resolution 60Hz with a maximum distance of 100m over Cat.6 cable.
- Features: HDMI audio transmission and separate audio ports for TosLink and 3.5mm connections.
- IR support for remote control and RS-232 serial interface for extended control capabilities.
- PoC (power delivery via cable) and ARC support are included for convenience.
Features | |
|---|---|
| Product type | AV Extender |
| Model | 100m Cat.6 HDMI 4K60, Audio, IR RS-232 HDBaseT Extender |
Specifications | |
| AV interface | HDMI® |
| Interface standard | 2.0 |
| Supported bandwidth | 18Gbps |
| Maximum resolution | 3840x2160@60Hz 4:4:4 8bit |
| HDCP support | 2.2 |
| EDID transmission | Sales |
| Supported audio | HDMI audio transmission, TosLink (optical) to 5.1Ch, 3.5mm to 2.0Ch |
| IR support | 20 - 60KHz |
| Serial interface | RS-232 |
| Transmission protocol | HDBaseT |
| Transmission medium | 1 x Cat.6 |
| Chipset | VS2310TX-A1 |
| Special features | PoC (power supply via cable), ARC support |
Connectors | |
| Sender input | HDMI® Type A (Female), 3.5mm IR (Female) |
| Sender output | RJ-45 (Female), TosLink (optical) (Female), 3.5mm audio (Female), 3.5mm IR (Female) |
| Receiver input | RJ-45 (Female), Toslink (optical) (Female), 3.5mm IR (Female) |
| Receiver output | HDMI® Type A (Female), 3.5mm IR (Female) |
| Two-way ports | RS-232 3-Pin Terminal Block, RJ-45 Ethernet (Female) |
| Power supply | 5.5/2.1mm |
Physical properties | |
| Dimensions (approximate) | 163x90x16mm (6.42x3.54x0.63in) per device |
| Housing | Metal |
| Net weight | 0.77kg (1.7lb) |
| Working temperature | 0°C - 40°C (32°F - 104°F) |
| Safety temperature | -20°C - 60°C (-4°F - 140°F) |
| Humidity | 20 - 90% RH (non-condensing) |
| Power requirements | 24VDC 1A |
| Color | Black |
Package contents | |
| Transmitter, Receiver, IR Send Cable (1.5m), IR Receiver Cable (1.5m), 4 x Mounting Ears 8 x Screws, 2 x 3-Pin Terminal Block, Multi-edge Power Supply (JK, EU, US AUS), Lindy Manual | |
www.lindy.lt
| Height | 70mm |
| Length | 265 mm |
| Weight | 1280g |
| Width | 210 mm |
