AV Extender - LINDY Cat.6A HDMI 4K60 HDBaseT 3.0 KVM Extender 100 m
Product reference:
14-4002888383448
Extend uncompressed HDMI signals up to 100m, supporting 4K resolution at 60Hz and 18Gbps bandwidth. The device features audio transmission, IR support, and RS-232 control via HDBaseT 3.0 technology.
AV Extender - LINDY Cat.6A HDMI 4K60 HDBaseT 3.0 KVM Extender 100 m
Product reference:
14-4002888383448
Extend uncompressed HDMI signals up to 100m, supporting 4K resolution at 60Hz and 18Gbps bandwidth. The device features audio transmission, IR support, and RS-232 control via HDBaseT 3.0 technology.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
LINDY Cat.6A HDMI 4K60 HDBaseT 3.0 KVM Extender 100 m
Extend uncompressed HDMI signals up to 100m, supporting 4K resolution 60Hz and 18Gbps bandwidth. Includes audio pass-through, IR support, and RS-232 control using HDBaseT 3.0 technology.
- Extends HDMI 4K60 video up to 100 m (328.08 ft) with HDBaseT 3.0 technology.
- Supports multiple audio formats, including HDMI® audio pass-through and TosLink up to 5.1Ch.
- Equipped with a USB Host/Device connector and PoC (power over cable) for easy setup.
- Added IR support and RS-232 for improved management and integration.
Features | |
|---|---|
| Product type | AV Extender |
| Model | 100m Cat.6A HDMI 4K60, Audio, IR and RS-232 HDBaseT 3.0 KVM Extender |
Specifications | |
| AV interface | HDMI® |
| Interface standard | HDMI 2.0, USB 2.0 |
| Supported bandwidth | 18Gbps |
| Maximum distance | 100m (328.08 feet) |
| Maximum resolution | 3840x2160@60Hz 4:4:4 8bit |
| HDCP support | 2.3 |
| EDID bandwidth | Throughput |
| IR support | 20 - 60KHz |
| Serial interface | RS-232 |
| Transmission protocol | HDBaseT 3.0 |
| Transmission medium | 1 x Cat.6A or higher |
| Chipset | VS3000 |
| Working temperature | 0°C - 40°C (32°F - 104°F) |
| Safety temperature | -20°C - 60°C (-4°F - 140°F) |
| Humidity | 20 - 90% RH (non-condensing) |
| Power requirements | 24VDC 1A |
| Dimensions (approximate) | 170x88x20mm (6.69x3.46x0.79in) per unit |
| Net weight | 1.143kg (2.52lb) |
| Housing | Metal |
| Color | Black |
Connectors | |
| Send input | HDMI® Type A (Female), USB Type B (Female), 3.5mm IR (Female) |
| Send output | HDMI® Type A (Female), RJ-45 (Female), TosLink (Optical) (Female), 3.5mm Audio (Female), 2 x USB Type A (Female) |
| Receiver input | RJ-45 (Female), USB Type B (Female), TosLink (Optical) (Female), 3.5mm IR (Female) |
| Receiver output | HDMI® Type A (Female), 2 x USB Type A (Female), 3.5mm Audio (Female), 3.5mm IR (Female) |
| Power connector | 5.5/2.1mm |
Safety warning | |
| Use the product only for its intended purpose to ensure safety and optimal performance. | |
www.lindy.lt
| Height | 75 mm |
| Length | 200mm |
| Weight | 1442 grams |
| Width | 290 mm |
