AV Extender - LINDY Cat.6 HDMI 4K60 HDBaseT Wall Plate Extender, PoC 70 m
Product reference:
14-4002888383486
Extends HDMI signals up to 70m using HDBaseT technology and supports resolutions up to 3840x2160@60Hz. Offers bi-directional IR, RS-232 pass-through and Power over Cable (PoC) functionality.
AV Extender - LINDY Cat.6 HDMI 4K60 HDBaseT Wall Plate Extender, PoC 70 m
Product reference:
14-4002888383486
Extends HDMI signals up to 70m using HDBaseT technology and supports resolutions up to 3840x2160@60Hz. Offers bi-directional IR, RS-232 pass-through and Power over Cable (PoC) functionality.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
LINDY Cat.6 HDMI 4K60 HDBaseT Wall Plate Extender, PoC 70 m
Extends HDMI signals up to 70m using HDBaseT technology, supporting resolutions up to 3840x2160@60Hz. Offers bi-directional IR, RS-232 passthrough and Power over Cable (PoC) functionality.
- Supports 4K resolution 60Hz with a maximum distance of 40 m (131.23 ft).
- Offers bidirectional IR and RS-232 bandwidth for improved control capabilities.
- Uses HDBaseT technology for reliable transmission over Cat.6 cables.
- Compact metal housing with elegant white panel design for easy integration.
Features | |
|---|---|
| Product Type | AV Extender |
| Model | 70m Cat.6 HDMI 4K60, IR RS-232 HDBaseT EU Wall Plate Extender |
Specifications | |
| AV Interface | HDMI® |
| Interface Standard | 2.0 |
| Supported Bandwidth | 18Gbps |
| Maximum Distance | 40 m (131.23 ft) - 3840x2160@60Hz 4:4:4 8bit; 70 m (229.66 ft) - 1920x1080@60Hz |
| Maximum Resolution | 3840x2160@60Hz 4:4:4 8bit |
| HDCP Support | 2.2 |
| EDID Bandwidth | Throughput |
| Supported Audio | Throughput |
| IR Support | 20 - 60KHz |
| Serial Interface | RS-232 Throughput |
| Transmission Protocol | HDBaseT |
| Transmission Medium | Cat.6 |
| Chipset | VS010 |
| Special Features | Bidirectional IR, PoC (Power over Cable) with On/Off switch |
Connectors | |
| Sender Input | HDMI® Type A (Female), 3.5mm IR (Female) |
| Sender Output | RJ-45 (Female), 3.5mm AND (Female) |
| Bidirectional Connectors | RS-232 3-Pin Terminal Block |
| Power supply | 2-Pin Terminal Block DC connector |
Physical Properties | |
| Dimensions (approximate) | 80x38.05x80mm (3.15x1.5x3.15in) |
| Housing Material | Metal |
| Net Weight | 0.39kg (0.86lb) |
| Operating Temperature | 0°C - 40°C (32°F - 104°F) |
| Storage Temperature | -20°C - 60°C (-4°F - 140°F) |
| Humidity | 20 - 90% RH (non-condensing) |
| Power Requirements | 24VDC 1A |
| Color | White plate |
Miscellaneous | |
| Packaging Type | Cardboard Box |
| Packaging Dimensions | 152x95x133mm (5.98x3.74x5.24in) |
| Total Weight | 0.54kg (1.19lb) |
| Product Compliance | CE, UKCA, FCC, RoHS, REACH California Proposition 65 |
Package Contents | |
| |
www.lindy.lt
| Height | 95 mm |
| Length | 152 mm |
| Weight | 540g |
| Width | 133 mm |
