AV Extender - LINDY Cat.6 HDMI 4K60 HDBaseT Matrix with 4 Receivers 150 m
Product reference:
14-4002888383455
Supports HDMI 4K60 resolution, maximum distance - 150 m, using HDBaseT technology. The kit includes a transmitter and four receivers with features such as PoC, EDID transmission and various audio options.
AV Extender - LINDY Cat.6 HDMI 4K60 HDBaseT Matrix with 4 Receivers 150 m
Product reference:
14-4002888383455
Supports HDMI 4K60 resolution, maximum distance - 150 m, using HDBaseT technology. The kit includes a transmitter and four receivers with features such as PoC, EDID transmission and various audio options.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
LINDY Cat.6 HDMI 4K60 HDBaseT Matrix with 4 Receivers 150 m
Supports HDMI 4K60 resolution with a maximum distance of 150 m using HDBaseT technology. The kit includes a transmitter and four receivers, with features such as PoC, EDID transmission and a variety of audio options.
- Supports 4K resolution at 60Hz frequency with a maximum distance of 150 m over Cat.6 cables.
- 4 HDMI receivers are included, allowing for smooth transmission of audio and video signals.
- The Power over Cable (PoC) feature simplifies installation and reduces clutter.
- Compatible with a variety of audio formats, including HDMI audio pass-through and digital audio up to 5.1 channels.
Features | |
|---|---|
| Product type | AV Extender |
| Model | 150m Cat.6 4x4 HDMI 4K60 HDBaseT Matrix Expansion Kit |
Specifications | |
| AV interface | HDMI® |
| Interface standard | 2.0 |
| Supported bandwidth | 18Gbps |
| Maximum distance | 120m (3840x2160@60Hz 4:4:4 8bit), 150m (1920x1080@60Hz) |
| Maximum resolution | 3840x2160@60Hz 4:4:4 8bit |
| HDCP support | 2.2 |
| EDID transmission | Presets, Cloning |
| Supported audio | HDMI® Audio Pass-through, Digital audio up to 5.1Ch, Analog audio up to 2.0Ch |
| IR support | 20 - 60KHz |
| Serial interface | RS-232 |
| Transmission protocol | HDBaseT |
| Transmission medium | 4 x Cat.6 |
| Special features | PoC (Power over Cable), HDMI® Loop Out connections, 4K to 1080p downscaling function |
Connectors | |
| Transmitter input | 4 x HDMI® (Female), 5 x 3.5mm IR (Female) |
| Transmitter output | 4 x HDMI® (Female), 4 x Coax RCA (Female), 4 x L/R Audio 5-pin phoenix, 5 x 3.5mm IR (Female), 4 x RJ45 HDBaseT (Female) |
| Receiver output | HDMI® (Female), 3.5mm Audio (Female), 3.5mm IR (Female) |
Physical properties | |
| Dimensions | Matrix: 440x200x45mm; Receivers: 140x65x18mm |
| Housing material | Metal |
| Net weight | 5.31Kg |
| Working temperature | 0°C- 40°C |
| Safety temperature | -20°C- 60°C |
| Humidity | 20- 90% RH (non-condensing) |
| Power | 60W |
| Color | Black |
Package contents | |
| 4x4 HDBaseT Expansion Matrix - Transmitter, 4 x HDBaseT Receivers, 5 x IR Transmitter Cable (1.5m), 5 x IR Receiver Cable (1.5m), 10 x Mounting Ears and Screws, 4 x 3-pin Terminal Block, 4 x 5-pin Terminal Block, RS-232 Male to Female Cable (1.5m), 4 x Power Cables (EU, JK, US and AUS, 1.5m), Lindy Manual | |
www.lindy.lt
| Height | 98 mm |
| Length | 403mm |
| Weight | 6330 grams |
| Width | 510mm |
