AV Extender - LINDY Cat.6 HDMI 4K60, Audio, IR and RS-232 HDBaseT Extender 70 m
Product reference:
14-4002888383493
Extends HDMI and ARC signals up to 70 meters, supporting a maximum resolution of 3840x2160 at 60Hz. Also supports bidirectional IR, RS-232 and has a bandwidth of 18Gbps.
AV Extender - LINDY Cat.6 HDMI 4K60, Audio, IR and RS-232 HDBaseT Extender 70 m
Product reference:
14-4002888383493
Extends HDMI and ARC signals up to 70 meters, supporting a maximum resolution of 3840x2160 at 60Hz. Also supports bidirectional IR, RS-232 and has a bandwidth of 18Gbps.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
LINDY Cat.6 HDMI 4K60, Audio, IR and RS-232 HDBaseT Extender 70 m
Extends HDMI and ARC signals up to 70 meters with maximum resolution of 3840x2160 60Hz. Supports bidirectional IR, RS-232 and has 18Gbps bandwidth.
- Extends HDMI® signals up to 70m (229.66ft) with 4K60 resolution support.
- There is bidirectional IR, audio pass-through, and RS-232 control.
- A multi-angle power supply is included and the design is easy to assemble with included accessories.
Features | |
|---|---|
| Product type | AV Extender |
| Model | 70m Cat.6 HDMI 4K60, Audio, IR RS-232 HDBaseT Extender with ARC |
Specifications | |
| AV interface | HDMI® |
| Interface standard | 2.0 |
| Supported bandwidth | 18Gbps |
| Maximum distance | 70m (229.66ft) |
| Maximum resolution | 3840x2160@60Hz 4:4:4 8bit |
| HDCP support | 2.2 |
| EDID bandwidth | Dip Switch with copy function |
| Supported audio bandwidth | Throughput |
| Separate audio ports | TosLink (Optical) |
| IR support | 20 - 60KHz |
| Serial interface | RS-232 bandwidth |
| Transmission protocol | HDBaseT |
| Transmission material | Cat.6 |
| Chipset | VS010-A0 |
| Special features | Bidirectional IR, PoC and ARC |
Connectors | |
| Sender input | HDMI® Type A (Female), 3.5mm IR (Female) |
| Sender output | RJ-45 (Female), TosLink (Optical) (Female), 3.5mm IR (Female) |
| Receiver input | RJ-45 (Female), TosLink (Optical) (Female), 3.5mm IR (Female) |
| Receiver output | HDMI® Type A (Female), 3.5mm IR (Female) |
| Bidirectional ports | RS-232 3-Pin Terminal Block |
| Power supply | 5.5/2.1mm |
Physical properties | |
| Dimensions (approximate) | 140x65x18mm (5.51x2.56x0.71in) for each unit |
| Housing material | Metal |
| Net weight | 0.76kg (1.68lb) |
| Operating temperature | 0°C - 40°C (32°F - 104°F) |
| Storage temperature | -20°C - 60°C (-4°F - 140°F) |
| Humidity | 20 - 90% RH (non-condensing) |
| Power requirements | 24VDC 1A |
| Color | Black |
Miscellaneous | |
| Packaging type | Cardboard box |
| Package dimensions | 245x75x185mm (9.65x2.95x7.28in) |
| Total weight | 0.94kg (2.07lb) |
| Product compliance | CE, UKCA, FCC, RoHS, REACH and California Proposition 65 |
Package contents | |
| |
www.lindy.lt
| Height | 75 mm |
| Length | 245 mm |
| Weight | 940g |
| Width | 185 mm |
