ATEN CS84U-AT KVM switch
Product reference:
29-4710423777019
ATEN 4-Port USB - PS/2 VGA KVM Switch (KVM Cables included), 2048 x 1536 pixels, QXGA, 0.45 W, Black, Grey
ATEN CS84U-AT KVM switch
Product reference:
29-4710423777019
ATEN 4-Port USB - PS/2 VGA KVM Switch (KVM Cables included), 2048 x 1536 pixels, QXGA, 0.45 W, Black, Grey
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
5 - 10
business days
ATEN 4-Port USB - PS/2 VGA KVM Switch (KVM Cables included). Keyboard port type: USB, Mouse port type: USB, Video port type: VGA. HD type: QXGA, Maximum resolution: 2048 x 1536 pixels, Video bandwidth: 60 Hz. Product colour: Black, Grey, Housing material: Metal. Power source: DC, Input voltage: 5 V, Power consumption (typical): 0.45 W. Width: 210 mm, Depth: 88 mm, Height: 55.5 mm
The CS84U PS/2-USB KVM Switch is a desktop control unit that allows users to access four computers from a single KVM console (PS/2 or USB keyboard and mouse, and VGA monitor). In addition, CS84U comes with ATEN's new Video DynaSync™ technology, which eliminates boot-up display problems and optimizes resolution.
1x CS84U PS/2-USB KVM Switch
2x 2L-5301UP PS/2-USB KVM Cables
2x 2L-5302UP PS/2-USB KVM Cables
1x User Instructions
Ports & interfaces
Number of computers controlled: 4
Keyboard port type: USB
Mouse port type: USB
Video port type: VGA
VGA (D-Sub) ports quantity: 4
Console ports: USB A, VGA (D-Sub)
USB 2.0 Type-A hub ports quantity: 2
USB connector type: USB Type-A
Feature: DC-in jack
Performance
HD type: QXGA
Maximum resolution: 2048 x 1536 pixels
Video bandwidth: 60 Hz
Scan interval: 3,5,10,20 s
Feature: DDC2B support
Design
Product colour: Black, Grey
Housing material: Metal
LED indicators: Yes
Feature: Push button
Feature: Hot keys
Power
Power source: DC
Input voltage: 5 V
Power consumption (typical): 0.45 W
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 0 - 80%
Storage relative humidity (H-H): 0 - 80%
Weight & dimensions
Width: 210 mm
Depth: 88 mm
Height: 55.5 mm
Weight: 1.51 kg
Packaging data
Package width: 100 mm
Package depth: 283 mm
Package height: 173 mm
Package weight: 1.69 kg
Packaging content
Feature: Quick installation guide
Feature: Manual
Logistics data
Master (outer) case net weight: 7.57 kg
Harmonized System (HS) code: 85176200
Master (outer) case width: 292 mm
Master (outer) case length: 517 mm
Master (outer) case height: 194 mm
Master (outer) case gross weight: 8.98 kg
Products per master (outer) case: 5 pc(s)
| Gamintojo kodas | CS84U |
| Weight | 1.68 kg |
