ATEN CS1824-AT-G KVM switch

ATEN 4-Port USB 3.0 4K HDMI KVMP™ Switch with Audio Mixer Mode. Keyboard port type: USB, Mouse port type: USB, Video port type: HDMI. HD type: 4K Ultra HD, Maximum resolution: 4096 x 2160 pixels, Video bandwidth: 60 Hz. Product colour: Black, Housing material: Metal, Plastic. Power source: DC, Input voltage: 5 V, Power consumption (typical): 2.535 W. Compliance certificates: RoHS

The ATEN CS1824 KVMP™ Switch offers effortless management of four HDMI interface computers from a single USB keyboard, mouse and HDMI monitor. Supporting the most superior video quality up to 4K DCI (4096 x 2160 @ 60Hz), the CS1824 optimizes user experience of multitasking.
1x CS1824 4-Port USB 3.0 4K HDMI KVMP™ Switch
4x LIN6-19V1-V18G HDMI 2.0 Cables
4x LIN6-11C1-E12G USB 3.0 Cables
4x LIN5-0205-21CG Audio Cables
1x LIN2-418K-E12G Power Cord
1x 0AD8-8005-40MG Power Adapter
1x User Instructions

Ports & interfaces

Number of computers controlled: 4
Keyboard port type: USB
Mouse port type: USB
Video port type: HDMI
HDMI ports quantity: 5
HDMI version: 2.0
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity: 4
Console ports: 3.5mm headphone, HDMI, USB A
Console USB ports quantity: 4
Feature: USB hub
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 2
USB connector type: USB Type-A, USB Type-B
Serial ports quantity: 1
Feature: Audio connections
Headphone outputs: 6
Feature: DC-in jack

Performance

HD type: 4K Ultra HD
Maximum resolution: 4096 x 2160 pixels
Video bandwidth: 60 Hz
Scan interval: 1,99 s
Feature: HDCP
Feature: Firmware upgradeable

Design

Product colour: Black
Housing material: Metal, Plastic
LED indicators: Yes
Feature: Push button

Power

Power source: DC
Input voltage: 5 V
Power consumption (typical): 2.535 W

Sustainability

Compliance certificates: RoHS

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 0 - 80%

Weight & dimensions

Width: 88 mm
Depth: 270 mm
Height: 55.5 mm
Weight: 2.24 kg

Packaging data

Package width: 98 mm
Package depth: 325 mm
Package height: 210 mm
Package weight: 2.54 kg

Logistics data

Master (outer) case net weight: 11.2 kg
Harmonized System (HS) code: 85176200
Master (outer) case width: 342 mm
Master (outer) case length: 512 mm
Master (outer) case height: 232 mm
Master (outer) case gross weight: 13.2 kg
Products per master (outer) case: 5 pc(s)
