ATEN CE700A-AT-G KVM extender

ATEN USB VGA KVM Extender (150m). Type: Transmitter & receiver, Connectivity technology: Wired, Maximum transfer distance: 150 m. Transmitter video port type: VGA, Transmitter local keyboard/mouse port type: USB. Receiver local video port type: VGA, Receiver local keyboard/mouse port type: USB. AC adapter output voltage: 5.3 V. Transmitter width: 12.7 cm, Transmitter depth: 8.65 cm, Transmitter height: 2.5 cm

The CE700A is a USB KVM Extender with superior video quality and built-in ESD and surge protection that allows access to a computer system up to 150 meters away from a remote USB console (USB keyboard, monitor, and USB mouse).

1x CE700AL USB KVM Extender (Local Unit)
1x CE700AR USB KVM Extender (Remote Unit)
2x 0AD6-1605-09EG Power Adapters
1x USB KVM Cable (1.8m)
1x Mounting Kit
1x User Instructions

Features

Type: Transmitter & receiver
Connectivity technology: Wired
Maximum transfer distance: 150 m
Cable types supported: Cat5e
Feature: Rack mounting
Supported resolutions: 1920 x 1200, 1600 x 1200, 1280 x 1024
Product colour: Black, Grey
Material: Metal
LED indicators: Link, Power

Transmitter

Transmitter video port type: VGA
Transmitter local keyboard/mouse port type: USB
RJ-45 ports quantity (transmitter): 1

Receiver

Receiver local video port type: VGA
Receiver local keyboard/mouse port type: USB
RJ-45 ports quantity (receiver): 1

Power

AC adapter output voltage: 5.3 V

Weight & dimensions

Transmitter width: 12.7 cm
Transmitter depth: 8.65 cm
Transmitter height: 2.5 cm
Transmitter weight: 330 g
Receiver width: 12.7 cm
Receiver depth: 8.14 cm
Receiver height: 2.5 cm
Receiver weight: 320 g

Packaging data

Package width: 100 mm
Package depth: 283 mm
Package height: 173 mm
Package weight: 1.41 kg

Packaging content

Feature: Manual
Feature: Quick installation guide

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 0 - 80%
Storage relative humidity (H-H): 0 - 80%

Technical details

Weight: 1.14 kg

Logistics data

Master (outer) case net weight: 5.67 kg
Harmonized System (HS) code: 84733080
Master (outer) case width: 300 mm
Master (outer) case length: 336 mm
Master (outer) case height: 194 mm
Master (outer) case gross weight: 6.86 kg
Products per master (outer) case: 5 pc(s)
