Connects a Mini DisplayPort device to a DVI display, supporting a maximum resolution of 1920x1200@60Hz. Features a passive converter design and supports HDCP 1.4 and 2.2 standards.
Connects a Mini DisplayPort device to a DVI display, supporting a maximum resolution of 1920x1200@60Hz. Features a passive converter design and supports HDCP 1.4 and 2.2 standards.



Connects a Mini DisplayPort device to a DVI display, supporting a maximum resolution of 1920x1200@60Hz. Features a passive converter design and supports HDCP 1.4 and 2.2 standards.
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
Connects a Mini DisplayPort device to a DVI display with a maximum resolution of 1920x1200@60Hz. Features a passive converter design and supports HDCP 1.4 and 2.2.
Features | |
|---|---|
| Product type | Adapter |
| Model | Mini Display Port to DVI converter |
Specifications | |
| AV interface | Mini DisplayPort to DVI |
| Interface standard | DisplayPort 1.1 |
| Supported bandwidth | 4.45Gbps |
| Maximum input resolution | 1920x1200@60Hz |
| Maximum output resolution | 1920x1200@60Hz |
| Chip | NXP PTN3361 |
| HDCP support | HDCP 1.4, HDCP 2.2 |
| Special features | Passive transducer |
Connectors | |
| Input | Mini DisplayPort (Male) |
| Output | DVI-I (Female) |
Physical properties | |
| Dimensions (WxDxH) | 18.9x11x9.3mm |
| Cable length | 180mm |
| Housing | ABS |
| Shell | PVC |
| Shell diameter | 5.5mm |
| Minimum bending radius | 33mm |
| Net weight | 0.035kg |
| Operating temperature | -20° to 40° |
| Storage temperature | -40° to +80° |
| Humidity | 20 - 90% RH (non-condensing) |
| Color | White |
Additional information | |
| Packaging type | Poly bag |
| Package dimensions | 176x194x20mm |
| Gross weight | 0.045kg |
| Product compliance | CE, UKCA, FCC, RoHS, REACH, California Prop. 65 |
| Height | 194 mm |
| Length | 174 mm |
| Weight | 45 g |
| Width | 20 mm |
