NET GATEWAY LTE I / O / TRB141 TELTONIKA
Product reference:
2-4779027312620
NET GATEWAY LTE I / O / TRB141 TELTONIKA
Product reference:
2-4779027312620
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
3 - 5
business days
This Industrial LTE Cat 1 Gateway is equipped with several Input & Output options including Digital, Relay, Analog and Isolated. Paired with secure and functional RutOS, plenty of processing power and Teltonika Remote Management System this device offers unprecedented application flexibility to manage and control equipment remotely over LTE. TRB141 is engineered to be used in Industrial applications therefore it has a wide range of software features such as SMS control, Firewall and FOTA support.
Standart package contains
- TRB141 Gateway
- Euro PSU
- 1 x LTE antenna (magnetic mount, SMA male, 3 m cable)
- Micro-USB cable (0.8 m)
- 1 x hex key
- I/O connector
- QSG (Quick Start Guide)
- Packaging box
- Multiple Inputs/Outputs for remote monitoring and control
- LTE Cat 1 for M2M/IoT communications
- Compact size, easy integration
- Wide range of power supply voltages
- Teltonika Remote Management System compatible
- Easy to use, secure and feature rich OpenWrt based Operating System
| Antenna connector type | SMA |
| Antenna type | External |
| Antennas quantity | 1 |
| Built-in processor | Yes |
| Certification | CE/RED, EAC, RoHS, WEEE Draft ETSI EN 301 489-1 V2.2.0, Draft EN 301 489-19 V2.1.0, Draft ETSI EN 301 489-52 V1.1.0 EN 61000-4-2:2009 EN 300 511 V12.5.1, ETSI EN 301 908-1 V11.1.1, ETSI EN 301 908-2 V11.1.2, ETSI EN 301 908-13 V11.1.2 EN 61000-4-3:2006 + |
| DC input voltage | 9 - 30 V |
| Depth | 18 mm |
| Dynamic DNS (DDNS) | Yes |
| Firewall security | Yes |
| Flash memory | 512 MB |
| Height | 60 mm |
| Internal memory | 128 MB |
| International Protection (IP) code | IP30 |
| LED indicators | Yes |
| MAC address filtering | Yes |
| Management protocols | HTTP/HTTPS, JSON-RPC, RMS |
| Manual | Yes |
| Model | TRB141 |
| NAT functionality | NAT, NAT-T |
| Number of processors installed | 1 |
| Number of simultaneous SIM cards | 1 |
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -40 - 75 °C |
| Processor frequency | 1200 MHz |
| Product colour | Grey |
| Product model code | TRB141003000 |
| Product Net Weight | 0.129 kg |
| Quick start guide | Yes |
| Reset button | Yes |
| Safety | IEC 62368-1:2014, EN 50385:2017, EN 62232:2017 |
| Security algorithms | 256-bit AES/DES/HTTPS/SSH/SSL/TLS |
| Short Message Service (SMS) | Yes |
| SIM card slot | Yes |
| SIM card type | MiniSIM |
| Summary | Teltonika TRB141. Product colour: Grey, International Protection (IP) code: IP30. Antenna type: External, Antenna connector type: SMA. Processor frequency: 1200 MHz, Internal memory: 128 MB, Flash memory: 512 MB. Management protocols: HTTP/HTTPS, JSON-RPC, RMS, Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SSL v3, TLS, SSH, DHCP, SNMP, MQTT. VPN support: OpenVPN, IPsec, GRE, PPTP, L2TP, NAT functionality: NAT, NAT-T |
| Supported network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SSL v3, TLS, SSH, DHCP, SNMP, MQTT |
| Unit Box Height | 0.07 |
| Unit Box Length | 0.175 |
| Unit Box Width | 0.15 |
| Unit Calculated Volume | 0.002396 cubm |
| Unit Calculated Weight | 0.462 kg |
| Units per Shipping Box | 10 |
| USB 2.0 ports quantity | 1 |
| Vendor Homepage | https://teltonika-networks.com/product/trb141/#description |
| VPN support | OpenVPN, IPsec, GRE, PPTP, L2TP |
| Web-based management | Yes |
| Weight | 136 g |
| Wi-Fi | No |
| Width | 70 mm |
| Wireless connection | Yes |
