The IC-A16 from Japanese firm ICOM is fully compliant with existing CAA regulations for 8.33KHz and 25kHz channel spacing for signal transmission and reception.
IC-A16E 8.33/25 kHz Ground to Air Support Radio
The IC-A16E 8.33/25 kHz ground to air support radio complements our growing 8.33kHz range of Airband radios. The IC-A16E air band transceiver has been specifically designed for airside ground crew who provide aviation support.
Major Selling Points
• Designed for ground crew who work in airports, airfield and who provide aviation support
• 8.33 kHz and 25 kHz channel spacing
• 1500 mW loud audio provides clear communication
• Large capacity battery pack provides 17 hours* of long battery life
* Typical operation with Tx : Rx (Max.audio) : standby=5:5:90. (Bluetooth OFF)
• 6 W (PEP) RF output power
• Compact, waterproof, durable body (IP67 and MIL-STD-810-G)
• LCD and keypad backlight for night time operation
• Built-in Bluetooth for Hands-Free Operation (dependent on version)
• Compatible with third-party aviation headsets (Optional OPC-2401 headset adapter is required)
Other Features
• Auto Noise Limiter (ANL) for noise reduction
• Side Tone function
• Internal VOX capability
• 200 memory channels with 8-character names
• BNC type antenna connector
Technical parameters
| General | |||||
| Frequency range |
| ||||
| Channel spacing | 25-8.33 kHz | ||||
| Number of memory channels | 200 | ||||
| Power supply | 7.2 V DC | ||||
| Current consumption (at 7.2 V) |
| ||||
| Temperature range | -20°C to +55°C | ||||
| Dimensions | 52.2 × 111.8 × 34.1 mm (with BP-280) | ||||
| Weight | 257 g (with BP-280) | ||||
| Antenna connector | BNC | ||||
| Transmitter | |||||
| Power (at 7.2 V DC) | 6.0 W typ. (PEP) 1.8 W typ. (Carrier) | ||||
| Receiver | |||||
| Intermediate frequencies | 1 - 46.35 MHzMHz, 2 - 450kHz | ||||
| Sensitivity | Less than 0 dBμ (at 12 dB SINAD with CCITT) | ||||
| Signal-to-noise ratio | More than 40 dB | ||||
| Side channel level | More than 70 dB | ||||
| Audio power | 1500 mW typical | ||||
