LINDY Cat.6 4x4 HDMI 4K60 and IR Matrix Extender, 70 m, Black
Extend 4K@60Hz resolution from 4 sources to 4 receivers over a maximum distance of up to 70m using Cat.6 cables. Supports HDMI 2.0, 18Gbps bandwidth and includes IR control and RS-232 connectivity.
- Supports 4K resolution at 60Hz with a maximum distance of 70m (229.66ft).
- There is RS-232 and Telnet control for easy management and operation.
- Includes multiple HDMI outputs and IR support for universal connectivity.
- The Power over Cable feature simplifies installation and reduces clutter.
Features | |
|---|---|
| Product Type | AV Matrix Expander |
| Model | 70m Cat.6 4x4 HDMI 4K60 Matrix Extender |
Specifications | |
| AV Interface | HDMI® |
| Interface Standard | 2.0 |
| Supported Bandwidth | 18Gbps |
| Maximum Resolution | 3840x2160@60Hz 4:4:4 8bit |
| HDCP Support | 2.2 |
| EDID Management | Advance or Copy Function |
| IR Support | 20~60KHz |
| Serial Interface | RS-232 |
| Transmission Medium | 1 x Cat.6 for each port |
| Chip | GSV |
| Special Features | RS-232 and Telnet Control, Mirrored HDMI® Outputs, Power over Cable, 4K to 1080 Downscaling for Each Port |
Connectors | |
| Sender Login | 4 x HDMI® Type A (Female) |
| Sender Exit | 4 x HDMI® Type A (Female), 4 x RJ-45 (Female), 4 x 3.5mm IR (Female), RJ-45 LAN Control (Female), 3-Pin Phoenix Connector (Female) |
| Receiver Input | RJ-45 (Female), 3.5mm IR (Female) |
| Receiver Output | HDMI® Type A (Female) |
| Power | 5.5/2.1mm |
Physical Properties | |
| Dimensions (Matrix Expander) | 320x100x36mm (12.6x3.94x1.42in) |
| Dimensions (Receiver) | 61x88x18mm (2.4x3.46x0.71in) |
| Housing Material | Metal |
| Net Weight (Matrix Expander) | 0.95kg (2.09lb) |
| Net Weight (Receiver) | 0.14kg (0.31lb) |
| Operating Temperature | 0°C - 40°C (32°F - 104°F) |
| Storage Temperature | -20°C - 60°C (-4°F - 140°F) |
| Humidity | 20-90% RH (non-condensing) |
| Power | 12VDC 2.5A |
| Color | Black |
Product Compliance | |
| Compliance Standards | CE, UKCA, FCC, RoHS, REACH and California Proposition 65 |
