Automotive Leak Detector - ANCEL L8000 20 PSI Diagnostic Leak Detector
Product reference:
14-6978281190601
Automotive leak detector with smoke and pressure drop testing for EVAP, intake, exhaust, vacuum, turbocharger, hoses and gasket systems. The built-in pump creates up to 20 psi of pressure, while the 4-inch color display, 12V DC power supply, adapters and 150ml of smoke fluid ensure convenient use.
Automotive Leak Detector - ANCEL L8000 20 PSI Diagnostic Leak Detector
Product reference:
14-6978281190601
Automotive leak detector with smoke and pressure drop testing for EVAP, intake, exhaust, vacuum, turbocharger, hoses and gasket systems. The built-in pump creates up to 20 psi of pressure, while the 4-inch color display, 12V DC power supply, adapters and 150ml of smoke fluid ensure convenient use.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
ANCEL L8000 20 PSI diagnostic leak detector
Automotive leak detector with smoke and pressure drop testing functions for testing EVAP, intake, exhaust, vacuum, turbocharger, hoses and gasket systems. Built-in pump creates pressure up to 20 psi. Equipped with a 4-inch color display, uses 12 V DC power supply. Includes adapters and 150 ml of smoke fluid.
- Professional automotive leak detector for detecting leaks in EVAP, intake, exhaust, vacuum, turbocharger, hoses and gasket systems.
- Low pressure EVAP mode and high pressure "Turbo" mode. Integrated pump creates pressure up to 20 PSI.
- Performs smoke and pressure drop tests, allows you to adjust the test pressure and duration.
- 4-inch color LCD display, self-test function and a wide range of adapters and accessories.
Product information | |
|---|---|
| Product type | Automotive systems leak detector |
| Brand | ANCEL |
| Model | L8000 |
| Main purpose | For detecting leaks in EVAP, intake, exhaust, vacuum, turbocharger, hoses, gaskets and dashboard systems |
Technical specifications | |
| Screen | 4-inch color LCD screen |
| Power supply | 12 V DC |
| Current in smoke mode | Less than 6.5 A |
| EVAP pressure | 0.44-0.5 psi (30-35 mbar) |
| High pressure pump | Maximum pressure - 20 psi (138 kPa) |
| Smoke flow | 6-8 l/min |
| Throughput | Less than 8 l/min |
| Air source | Integrated pump |
| Power cord length | About 2.5 m |
| Smoke hose length | About 2.5 m |
| Dimensions | 280 × 250 × 260mm |
| Weight | 4.75 kg |
| Operating temperature | −17 ° C-60 °C |
Features and compatibility | |
| Test modes | Low pressure EVAP mode and high pressure "Turbo" mode |
| Diagnostic functions | Smoke and pressure drop tests, adjustable test pressure and duration, and device self-diagnostics |
| Operating modes | Professional mode with preset configurations and custom mode with manually adjustable pressure |
| Settings | Selectable language, pressure units and audible warning |
| Supported vehicles | Cars, trucks and other compatible vehicles; application depends on vehicle |
| Supported languages | English, Spanish, Portuguese, German, French, Italian, Finnish, Polish and Turkish |
Included accessories | |
| Complete set |
|
Safety warning | |
| Safe use | Use only for automotive leak diagnosis and do not exceed the specified pressure range. Follow the vehicle manufacturer's maintenance procedures, keep the unit away from open flames and ignition sources, ensure adequate ventilation, and wear appropriate eye and hand protection. Disconnect power before servicing the unit. |
| Height | 300mm |
| Length | 400mm |
| Weight | 6000 grams |
| Width | 300mm |
