The Lindy 70m Cat.6 4 Port HDMI 4K60 Splitter Extender is a simple, professional solution for distribution of 4K HDMI signals to multiple displays using standard Cat.6 network cables.
Scalable Content DistributionThis Cat.6 splitter allows for distribution to up 4 remote locations using the included receivers, at up to 70m in distance, ideal for sharing content simultaneously in sports bars or events. The local HDMI output on the splitter allows for monitoring using a connected display, or alternatively can be combined with up to 2 additional Cat.6 splitters for even larger scale content distribution.
Immersive 4K and HDR SupportWith support for resolutions up to 3840x2160@60Hz, this splitter ensures superior clarity of high-quality video, including movies, sports, games, or live monitoring. HDR support ensures a much wider colour gamut is visualised, alongside a higher peak brightness and deeper blacks for an enhanced dynamic contrast. This provides an eye-catching and engaging experience for the viewer in a variety of different applications including digital signage in retail, content delivery in lecture halls, or information broadcasting in travel hubs.
Seamless IR ControlThe included IR cables allow for simple control via an IR remote from any of the receiver locations, removing the need to be situated at the source side on the setup.
Simultaneous PoC DistributionThe Cat.6 HDMI 4K60 Splitter also support PoC (Power over cable) allowing for power to be distributed alongside audio and video over the cat.6 cabling. This allows for only one power source being required at the transmitter side, ensuring a minimalist and time-saving setup at the receiver locations.
Please Note: The quoted resolutions are possible with a direct connection between transmitter and receiver using good quality Cat.6 solid core cable. Using a different cable type, introducing wall plates, couplers or patch panels will result in a reduction of maximum distances.
| Bruto svoris | 1.95 kg |
| Darbo santykinės drėgmės diapazonas | 5 - 90 % |
| Darbo temperatūros diapazonas (TT) | 0 - 50 °C |
| DC įėjimo lizdas | Taip |
| HDCP | Taip |
| HDCP versija | 2.2 |
| HDMI išvesčių skaičius | 5 |
| HDMI versija | 2.0 |
| HDMI įvestis | 1 |
| Imtuvo matmenys (W x D x H) | 100 x 88 x 23 mm |
| Imtuvo svoris | 199 g |
| Instrukcija | Taip |
| Išplėstiniai ekrano identifikacijos duomenys (EDID) | Taip |
| Lustų rinkinys | GSV2006, GSV5100 |
| Maksimali rezoliucija | 3840 x 2160 pikseliai |
| Maksimalus atnaujinimo dažnis | 60 Hz |
| Maksimalus perdavimo atstumas | 70 m |
| Medžiaga | Metalas |
| Model name | 70m Cat.6 4 Port HDMI 4K60 Splitter Extender |
| Neto svoris | 0.589 kg |
| Nuotolinio valdymo (IR) išvestis | 1 |
| Nuotolinio valdymo (IR) įvestis | 4 |
| Paketo svoris | 2000 g |
| Pakuotės aukštis | 354 mm |
| Pakuotės gylis | 60 mm |
| Pakuotės plotis | 423 mm |
| Pakuotės tipas | "Box" |
| Palaikomi audio formatai | LPCM |
| Palaikomi laido tipai | Cat6 |
| Pralaidumas | 18 Gbit/s |
| Pridėti kabeliai | IR/IR jutiklis |
| Pridėti montavimo kronšteinai | Taip |
| Produkto spalva | Juoda |
| RJ-45 išvesties prievadai | 4 |
| RJ-45 įvesties prievadai | 4 |
| Ryšio technologija | Vielinis |
| Sandėliavimo temperatūros norma (T-T) | -10 - 80 °C |
| Sertifikavimas | CE, UKCA, FCC, RoHS, REACH & California Propositon 65 |
| Shipping Box Depth | 42.5 cm |
| Shipping Box Height | 6 cm |
| Shipping Box Weight | 1.95 kg |
| Shipping Box Width | 34.8 cm |
| Siųstuvo matmenys (P x G x A) | 180 x 103 x 23 mm |
| Siųstuvo svoris | 390 g |
| Summary | Lindy 70m Cat.6 4 Port HDMI 4K60 Splitter Extender. Type: AV transmitter & receiver, Maximum resolution: 3840 x 2160 pixels, Cable types supported: Cat6. Connectivity technology: Wired. Receiver dimensions (WxDxH): 100 x 88 x 23 mm, Receiver weight: 199 g, Transmitter dimensions (WxDxH): 180 x 103 x 23 mm. Package width: 423 mm, Package depth: 60 mm, Package height: 354 mm. Cables included: IR, IR sensor |
| Tipas | AV siųstuvas ir imtuvas |
| Unit Box Height | 0.06 |
| Unit Box Length | 0.425 |
| Unit Box Width | 0.348 |
| Unit Brutto Volume | 0.008874 cubm |
| Vendor Homepage | https://www.lindy.co.uk/audio-video-c2/extenders-c181/70m-cat-6-4-port-hdmi-4k60-splitter-extender-p14132 |
| Vieneto aukštis | 6 cm |
| Vieneto gylis | 42.5 cm |
| Vieneto plotis | 34.8 cm |
| Vienetų skaičius vienoje siuntimo dėžėje | 1 |
