GPS / GNSS UMTS LTE 5G WLAN 76° Roof Antenna

Roof antenna AM/FM DAB+ / DVB-T2 76° active 12V ATTB 3792.01 ATTB 3792.01 is a 16V active roof antenna designed for receiving AM/FM, DAB+ or DVB-T2 in the car. The product comes from a German manufacturer Antennentechnik Bad Blankenburg, which has been developing professional antenna solutions "Made in Germany" since 1919. The antenna features a 230 mm low-noise rod, RG174 cables, and separate signal paths for individual services. It can operate with an external power supply or phantom power, making it ideal for complex radio and multimedia installations. The ATTB 3792.01 active antenna for car radio and multimedia supports AM/FM radio, DAB+ digital radio, and DVB-T2 reception. This makes it suitable for cars with modern multimedia units, DAB+ tuners, and TV systems. The antenna offers signal amplification for AM, FM, DAB+, and DVB-T. The active design helps achieve more stable reception, especially in installations where signal quality and interference immunity are important. Key advantages of the ATTB 3792.01 antenna

• original ATTB roof antenna Made in Germany,
• 16V style with a 76° inclination,
• AM/FM, DAB+ and DVB-T2 support,
• active design with separate signal routing,
• external or phantom power supply,
• low-noise antenna rod 230 mm,
• RG174 cables,
• Fakra connectors for integration with the car's installation,
• FM gain 15 dB,
• DAB+ BIII gain 15 dB,
• DVB-T IV/V gain 12 dB,
• impedance 50 Ohm,
• VSWR <2.0:1 for supported bands.

Made in Germany - Quality Antennentechnik Bad Blankenburg Antennentechnik Bad Blankenburg is a German manufacturer of car antennas and antenna accessories. The company develops solutions for standards such as AM/FM, DAB+, DVB-T, GPS, LTE, 5G, GSM, WLAN, Bluetooth, and TETRA. The production process of ATTB antennas is certified according to automotive industry standards. The manufacturer monitors the quality of antennas at its own test stations from the design stage, through series production, to final inspection. This makes the ATTB 3792.01 antenna suitable for demanding automotive installations. Applications: The ATTB 3792.01 roof antenna is designed for receiving radio and multimedia signals in cars. It can be used when replacing an antenna, upgrading a radio system, or installing a system supporting DAB+ and DVB-T2. The product is suitable for applications such as:

• AM/FM radio reception,
• DAB+ digital radio reception,
• DVB-T2 reception in the car,
• installations with multimedia radios,
• expansion of car audio systems,
• installation in passenger cars, vans, campers and special vehicles.

Important installation information: A suitable antenna splitter is required for simultaneous DAB+ and DVB-T2 reception. The manufacturer's specifications specify a DAB/DAB+/DVB-T splitter: 2x Fakra Z(m) 1x Fakra Z(f), item number 153-4738-01. To achieve the best reception, ensure proper grounding of the antenna base or ground strap. During installation, it is recommended to remove paint from the contact points and protect the area from corrosion with contact paste. For better contact, also protect the antenna rod thread and the antenna base thread. If reception problems occur, check the antenna cables, adapters, and the quality of the connections. It is also worth verifying whether additional LED lighting, USB chargers, voltage converters, power supplies, or digital power amplifiers are causing interference. Technical data

• Producer: Antennentechnik Bad Blankenburg / ATTB
• Model: 3792.01
• Style: 16V
• Product type: active AM/FM DAB+ / DVB-T2 roof antenna
• Tilt: 76°
• Antenna rod: low-noise, 230 mm
• Design: active antenna with separate signal routing
• Power supply: external or phantom
• Cable type: RG174
• AM/FM connector: Fakra B(m), white
• DAB+ / DVB-T2 connectors: Fakra G(m), Fakra E(m), Fakra H(m)
• AM/FM connection: Fakra B(m) white RG174 / L=185 mm
• DAB+ / DVB-T2 connection: Fakra G(m) gray / Fakra E(m) green / Fakra H(m) purple RG174 / L=250 mm
• External power supply: 6.3 mm flat connector
• AM range: 150 kHz - 1710 kHz
• FM range: 87.5 MHz - 108 MHz
• DAB+ BIII range: 174 MHz - 230 MHz
• DVB-T IV range: 474 MHz - 602 MHz
• DVB-T V range: 610 MHz - 768 MHz
• AM profit: 5 dB
• FM Profit:
