Thermal Imager - DALI 640×512 35 mm, 12.5° Field of View, 4× Digital Zoom, GPS, Wi-Fi, Laser Rangefinder, 32 GB
Product reference:
14-9990000991341
Thermal monocular with 640 × 512 resolution uncooled VOx sensor, 35 mm lens, 12.5° × 10° field of view, 4× digital zoom and 1280 × 960 resolution display. The device has integrated GPS, laser rangefinder, Wi-Fi, image and video recording, 32 GB internal memory, USB-C charging and IP66 protection.
Thermal Imager - DALI 640×512 35 mm, 12.5° Field of View, 4× Digital Zoom, GPS, Wi-Fi, Laser Rangefinder, 32 GB
Product reference:
14-9990000991341
Thermal monocular with 640 × 512 resolution uncooled VOx sensor, 35 mm lens, 12.5° × 10° field of view, 4× digital zoom and 1280 × 960 resolution display. The device has integrated GPS, laser rangefinder, Wi-Fi, image and video recording, 32 GB internal memory, USB-C charging and IP66 protection.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
4 - 5
business days
DALI 640×512 35 mm thermal monocular
Thermal monocular with 640×512 resolution uncooled VOx sensor, 35 mm lens, 12.5° × 10° field of view, 4× digital zoom and 1280×960 resolution display. The device has GPS, laser rangefinder, Wi-Fi, image and video recording, 32 GB internal memory, USB-C charging and IP66 protection.
- The 640×512 resolution uncooled VOx thermal sensor with a 35 mm lens and 12.5° × 10° field of view ensures clear observation at long distances in complete darkness.
- The integrated laser rangefinder measures distances from 10-1,000 m. There's also GPS, a digital compass, hotspot detection, and picture-in-picture.
- It supports smooth 1-4× digital zoom, four image palettes, photo and video recording, as well as streaming via Wi-Fi to smart devices.
- Rugged IP66 housing, over 6 hours of battery life, USB Type-C charging, and 32 GB of internal storage, expandable up to 256 GB.
Product Overview | |
|---|---|
| Product type | Thermal monocular |
| Model | DALI 640×512 35 mm thermal monocular |
| Main purpose | Handheld thermal imaging in complete darkness and low light |
Optical and thermal specifications | |
| Thermal sensor | 640 × 512 resolution uncooled VOx infrared detector |
| Lens focal length | 35mm |
| Field of view | 12.5° × 10° |
| Spectral range | 8-14 µm |
| Thermal sensitivity | Less than 40 mK at 30 °C |
| Frame rate | 50Hz |
| Screen resolution | 1280 × 960 pixels |
| Digital zoom | Even 1×-4× |
| Video modes | Black hot, white hot, red hot and pseudo color fusion |
| Picture in picture | 2× magnified image while maintaining a wider field of view |
| Diopter adjustment | Adjustable with a rotary dial |
Measurement and navigation | |
| Laser distance meter | 10-1,000 m measurement range |
| Rangefinder accuracy | ±1m |
| Hotspot detection | Shows the hottest object in the field of view |
| Digital compass | Integrated |
| GPS | Integrated |
| Detection distance | Up to 1,400 m for a person and 2,200 m for a vehicle, depending on environmental conditions |
| Recognition distance | Up to 700 m for a person and 1,100 m for a vehicle, depending on environmental conditions |
Recording and connectivity | |
| Recording images and videos | Integrated photo and video recording functions |
| Internal memory | 32GB |
| Expandable memory | Supports memory cards up to 256 GB |
| Wireless connectivity | Wi-Fi streaming and data transfer to compatible smart devices |
| USB interface | USB Type-C for charging, external power supply and data transfer |
Power supply and construction | |
| Battery | Rechargeable lithium-ion battery |
| Operating time | More than 6 hours of continuous operation |
| External power supply | 5V/2A via USB Type-C; compatible with external batteries |
| Protection from environmental influences | IP66: complete protection against dust and strong water jets |
| Operating temperature | −20-+50°C |
| Storage temperature | −40-+70°C |
| Impact resistance | Up to 1 m drop |
| Dimensions | 220 × 105 × 65mm |
| Weight | 550g |
| Tripod connector | Standard 1/4 inch thread |
Included accessories | |
| Complete set | Thermal monocular, USB Type-C cable with USB and RCA connectors, and wrist strap |
Safety warning | |
| Important safety information | Use the monocular only for its intended purpose - thermal observation. Do not look directly at people, vehicles or other objects when the laser rangefinder or laser pointer is on. Do not point the laser at aircraft, road vehicles or reflective surfaces. Protect the device and battery from fire, extreme heat and moisture exceeding the IP66 protection limits. Comply with local laws and regulations when observing, recording or using the distance measurement functions. |
| Height | 180mm |
| Length | 70mm |
| Weight | 680g |
| Width | 70mm |
