Power Supply, CHIEFTEC, BDF-500S, PS / 2, PC, 115 - 230 V, 500 W, BDF-500S
Product reference:
2-4710713231269
Power Supply, CHIEFTEC, BDF-500S, PS / 2, PC, 115 - 230 V, 500 W, BDF-500S
Product reference:
2-4710713231269
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
3 - 5
business days
Блок живлення ATX 2.3 Chieftec PROTON 500W 80 PLUS Bronze Black (BDF-500S)
With the PROTON Series, CHIEFTEC advances into the new-age DC to DC power supply technology. The series allows for energy conservation, as well as a much higher efficiency and power stability, which in turn ensures a higher longevity of installed components. The efficiency of the PROTON Series is certified at 80 PLUS BRONZE thereby fulfilling all ENERGY STAR 5,0 and higher requirements as stipulated by the EU.
| 80 PLUS certification | 80 PLUS Bronze |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 115 - 230 V |
| ATX version | 2.3 |
| Cabling type | Non-Modular |
| Combined power (+3.3V) | 90 W |
| Combined power (+5V) | 90 W |
| Connector(s) | 20+4 PIN ATX 1 8 PIN EPS (4+4) 1 8 PIN PCIe (6+2) 2 SATA 6 MOLEX 3 |
| Cooling type | Active |
| CPU power connector (4+4 pin) | Yes |
| Depth | 140 mm |
| Efficiency | 85 % |
| Fan diameter | 120 mm |
| Fan location | Top |
| Harmonized System (HS) code | 84733020 |
| Height | 87 mm |
| Manual | Yes |
| Max output current (+12V) | 41.68 A |
| Max output current (+3.3V) | 18 A |
| Max output current (+5V) | 18 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (-12V) | 0.3 A |
| Model name | BDF-500S |
| Motherboard power connector | 24-pin ATX |
| Number of fans | 1 fan(s) |
| Number of SATA power connectors | 6 |
| On/off switch | Yes |
| Package type | Box |
| PCI Express power connectors (6+2 pin) | 2 |
| Peripheral (Molex) power cable length | 150/400 mm |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Over voltage/Overload/Short circuit/Under voltage |
| Power supply unit (PSU) form factor | PS/2 |
| Product colour | Black |
| Product Net Weight | 1 kg |
| Purpose | PC |
| SATA power cable length | 150/400 mm |
| Shipping Box Depth | 54 cm |
| Shipping Box Height | 25 cm |
| Shipping Box Weight | 22 kg |
| Shipping Box Width | 51 cm |
| Summary | Chieftec BDF-500S. Total power: 500 W, AC input voltage: 115 - 230 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: PS/2, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 87 mm |
| Total power | 500 W |
| Unit Box Height | 0.18 |
| Unit Box Length | 0.25 |
| Unit Box Width | 0.1 |
| Unit Calculated Volume | 0.006885 cubm |
| Unit Calculated Weight | 2.2 kg |
| Unit Depth | 25 cm |
| Unit Height | 18 cm |
| Unit Width | 10 cm |
| Units per Shipping Box | 10 |
| Vendor Homepage | https://www.chieftec.eu/products-detail/159/PROTON_SERIES/163/BDF-500S |
| Warranty card | Yes |
| Width | 150 mm |
