Epson PLQ-35 dot matrix printer

Epson PLQ-35. Maximum print speed: 540 cps, Maximum resolution: 180 x 360 DPI, Maximum print speed (draft): 360 cps. Multi-part paper thickness range: 0.12 - 0.53 mm, Single sheet thickness range: 0.065 - 0.19 mm. Product colour: White, Buffer size: 128 KB, Sound pressure level (printing): 55 dB. Standard interfaces: Parallel, RS-232, USB 2.0. Print head: 24-pin, Print head life: 400 million characters, Mean time between failures (MTBF): 35000 h
Fast, quiet passbook printer
A quiet, fast and power-efficient passbook printer with a low TCO, ideal for financial and government institutions.
Customers and staff alike will appreciate the PLQ-30's unobtrusive noise levels, which are as low as 55dBA. It's efficient, too - the print speed enhancer enables fast printing of bit image data under Windows environments to help cut queues.
Low total cost of ownership
Delivering substantial cost and energy savings, the PLQ-30 has a very low standby power consumption of 4.5W. Further reducing TCO, it can print around 10 million characters in draft mode between ribbon changes.
Flexible
It offers excellent passbook handling and data processing flexibility, thanks to its 128kb memory and capacity for passbooks up to 2.6mm thick.
Easy installation
Simple to install, the PLQ-30 features a choice of emulations plus parallel, serial and USB interfaces as standard for an easy fit into most IT environments.
Ultra-high-speed draft mode
High speed print speeds of 585 cps.

Printing

Maximum resolution: 180 x 360 DPI
Maximum printing width (columns): 94
Maximum print speed: 540 cps
Maximum print speed (draft): 360 cps
Maximum print speed (LQ): 120 cps
Maximum print speed (NLQ): 180 cps
Character pitch: 10 cpi
Maximum number of copies: 6 copies
Built-in barcodes: CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Bitmap fonts: Courier, Draft, OCR-B, Orator, Orator-S, Prestige, Roman, Sans Serif, Script, Script C
Scalable fonts: Roman T, Sans Serif H
Character sets: PCAPTEC, PC437, PC708, PC720, PC850, PC858, PC864, PCAR864, ISO 8859-15, Roman 8, Italic
Number of characters: 14

Paper handling

Multi-part paper thickness range: 0.12 - 0.53 mm
Single sheet thickness range: 0.065 - 0.19 mm

Features

Product colour: White
Buffer size: 128 KB
Sound pressure level (printing): 55 dB
Page description languages: Epson ESC/P2, PPDS
Country of origin: Indonesia

Ports interfaces

Standard interfaces: Parallel, RS-232, USB 2.0

Endurance

Print head: 24-pin
Print head life: 400 million characters
Mean time between failures (MTBF): 35000 h

Power

Power consumption (typical): 61 W
Power consumption (standby): 0.7 W
AC input voltage: 220-240 V
AC input frequency: 50 - 60 Hz

Operational conditions

Operating temperature (T-T): 5 - 38 °C
Storage temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 10 - 85%

Weight dimensions

Width: 384 mm
Depth: 280 mm
Height: 203 mm
Weight: 7.8 kg

Packaging data

Quantity per pack: 1 pc(s)
Package width: 365 mm
Package depth: 455 mm
Package height: 255 mm
Package weight: 9.27 kg

Other features

Print technology: Dot matrix
Needles: 24 (2 x 12)

Logistics data

Products per pallet (UK): 48 pc(s)
Pallet weight (UK): 0 g
Harmonized System (HS) code: 84433210
