Switching power supply 24V 36W 1.5A, DIN rail mount, MEAN WELL, HDR-30-24
Product reference: 26-4711287421698
  • Type: Switching power supply
  • Model: HDR-30-24
  • Input voltage: 85-264 VAC (max. 277 VAC)
  • Output voltage: 21.6-29 VDC
  • Power: 36W
  • Current: 1.5 A
  • Temperature range: -30°C ÷ +70°C
  • Mounting: On DIN 35 mm rail
  • With potentiometer
  • Protection class: OVC III
  • Dimensions: 35x90x54.5 mm
  • Brand: MEAN WELL
Switching power supply 24V 36W 1.5A, DIN rail mount, MEAN WELL, HDR-30-24

Switching power supply 24V 36W 1.5A, DIN rail mount, MEAN WELL, HDR-30-24

Product reference: 26-4711287421698
  • Type: Switching power supply
  • Model: HDR-30-24
  • Input voltage: 85-264 VAC (max. 277 VAC)
  • Output voltage: 21.6-29 VDC
  • Power: 36W
  • Current: 1.5 A
  • Temperature range: -30°C ÷ +70°C
  • Mounting: On DIN 35 mm rail
  • With potentiometer
  • Protection class: OVC III
  • Dimensions: 35x90x54.5 mm
  • Brand: MEAN WELL
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
2581 €
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
2 - 6
business days

Your message has been successfully sent!
Fill in the required fields*
Not available
  • Home
  • Model HDR-30-24
  • DC voltage 24V
  • Rated current 1.5A
  • Current range 0 ~ 1.5A
  • Power 36W
  • Voltage regulation range 21.6 ~ 29V
  • Ripple Noise (max.) 150mVp-p
  • Voltage tolerance ±1.0%
  • Linear regulation ±1.0%
  • Load regulation ±1.0%
  • Setup and startup time 500ms, 50ms/230VAC; 500ms, 50ms/115VAC at full load
  • Retention time (typ.) 30ms/230VAC; 12ms/115VAC at full load
  • Voltage range 85~264VAC; 120 ~ 370VDC (277VAC operational, 390VDC operational)
  • Frequency range 47~63Hz
  • Performance (typ.) 89%
  • Alternating current (typ.) 0.88A/115VAC; 0.48A/230VAC
  • Inrush current (typ.) Cold start 25A/115VAC; 45A/230VAC
  • Overload protection 105 ~ 160% rated output power
  • Surge protection Shut down output voltage, re-power on to recover
  • Voltage withstand I/PO/P: 4KVAC
  • Insulation resistance I/PO/P: 100M Ohms / 500VDC / 25°C / 70% RH
  • Operating temperature -30 ~ +70°C (Refer to "Derating Curve")
  • Moisture resistance 20 ~ 90% RH non-condensing
  • Storage temperature and humidity -40 ~ +85°C, 10 ~ 95% RH non-condensing
  • Temp. Coefficient ±0.03%/°C (0 ~ 50°C) RH non-condensing
  • Vibration 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Compliance to IEC60068-2-6
  • MTBF 3670.4K hrs min. (Telcordia SR-332); 968.1K hrs min. (MIL-HDBK-217F at 25°C)
  • Size 35mm (W) x 90mm (H) x 54.5mm (D)
  • Weight 0.13Kg; 96pcs/14.2Kg/1.04CUFT
  • Certificates IEC62368-1, UL62368-1, UL508, BS EN/EN61558-2-16, BSMI CNS15598-1, EAC TP TC 004
  • EMC radiation BS EN/EN55032 (CISPR32), CNS15936 Class B
  • EMC immunity BS EN/EN61000-4-2, BS EN/EN61000-4-3, BS EN/EN61000-4-4, BS EN/EN61000-4-5, BS EN/EN61000-4-6, BS EN/EN61000-4-8, BS EN/EN61000-4-11
  • Working height Up to 2000 meters
  • LED indicator Power On
  • Cooling method Free air convection
  • Installation Type DIN Rail TS35/7.5 or TS35/15

Weight0.123 kg
